DC-Coupled Evaluation Kit
Independent Power-Supply Connections
Fully Assembled and Tested
SMA Connectors for CML Inputs and Outputs
Additional Transmission Lines for Calibration
Evaluates: MAX3841
____________________Component List
DESIGNATION
C1, C7, C13,
C22, C27, C30
C2, C8, C12,
C14, C26, C29
C3, C4, C6, C9,
C10, C11, C16,
C17, C23, C24,
C25, C28
C5, C15,
C18鈥揅21
J1鈥揓8, J10, J12,
J14, J16
JU1, JU3, JU8,
JU9
JU2, JU4鈥揓U7
JU1鈥揓U9
L1鈥揕6
TP5鈥揟P10, J9,
J11, J13, J15,
J18, J19, J20
U1
None
QTY
6
6
DESCRIPTION
33碌F
鹵10%
tantalum capacitors
(B case)
2.2碌F
鹵10%
ceramic capacitors
(0805)
0.01碌F
鹵10%
ceramic capacitors
(0201)
0.1碌F
鹵10%
ceramic capacitors
(0402)
SMA connectors
(edge mount, tab contact)
3-pin headers, 0.1in centers
2-pin headers, 0.1in centers
Shunts
Digi-Key S9000-ND
56nH inductors
Coilcraft 0805CS-560XKBC
Test points
Digi-Key 5000K-ND
MAX3841ETG 24-pin Thin QFN
MAX3841 EV kit circuit board,
Rev A
______________ Ordering Information
PART
MAX3841EVKIT
TEMP RANGE
-40擄C to +85擄C
IC PACKAGE
24 Thin QFN
________________________ Quick Start
Caution:
The MAX3841 EV kit is a DC-coupled
evaluation board. Each CML input and output is
terminated with 50鈩?to the respective I/O supplies. DC-
coupled operation with positive I/O supplies may cause
permanent damage to laboratory test equipment
(oscilloscope, BERT). The I/O supplies must be
connected to ground and a negative supply connected
to V
EE
when DC-coupling to laboratory test equipment.
1)
Connect the I/O supplies to ground and disconnect
V
EE
from ground by placing shunts on JU2, JU4,
JU5, JU6, and removing the shunt from JU7.
Enable both outputs by placing shunts across pins
1 and 2 of JU8 and JU9.
Configure the crosspoint switch to route IN1 to both
OUT1 and OUT2 by placing shunts across pins 2
and 3 of JU1 and across pins 1 and 2 of JU3.
Connect a +1.5V power supply to J13 (V
CC
).
Connect the power-supply ground to J19 (GND).
Connect a -1.8V power supply to J20 (V
EE
).
Apply a 10Gbps differential signal (150mV
P-P
to
1200mV
P-P
) to SMA connectors J1 (IN1+) and J2
(IN1-).
Connect an oscilloscope with 50鈩?terminations to
SMA connectors J5 (OUT1-), J6 (OUT1+), J7
(OUT2+), and J8 (OUT2-).
12
6
12
4
5
9
6
13
1
1
2)
3)
4)
______________ Component Suppliers
SUPPLIER
AVX
Coilcraft
Digi-Key
Murata
PHONE
843-448-9411
847-639-6400
800-344-4539
770-436-1300
FAX
843-626-3123
847-639-1469
218-681-3380
770-436-3030
5)
6)
Note:
Please indicate that you are using the MAX3841 when
ordering from these suppliers.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
