MAX3822EVKIT Datasheet

  • MAX3822EVKIT

  • Evaluation Kit for the MAX3822

  • Maxim   Maxim

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

19-2144; Rev 0; 8/01
MAX3822 Evaluation Kit
General Description
The MAX3822 evaluation kit (EV kit) is a fully assembled
demonstration board that simplifies evaluation of the
MAX3822 quad limiting amplifier. The EV kit is shipped
from the factory with all components needed to inter-
face with standard 50鈩?test equipment. The kit features
on-board power-supply filtering and consumes approxi-
mately 240mA with a +3.3V supply. To facilitate evalua-
tion of the MAX3822 at speed, the EV kit is laid out with
50鈩?controlled impedance on all signal lines.
o
Fully Assembled and Tested
o
Easy Loss-of-Power (LOP) Threshold
Programming
o
LOP Indicators
o
Channel-Select Configuration Pins
Features
Evaluates: MAX3822
Component List
DESIGNATION
C1鈥揅16, 21, 25,
28
C17鈥揅20
C26
C27
J1鈥揓8, J10鈥揓17
J9, J18鈥揓22
J23, J24
J23, J24
L1, L2
LED1鈥揕ED5
R1鈥揜5
R6
R7
R8
U1
VCC, GND
None
None
None
QTY
19
4
1
1
16
6
2
2
2
5
5
1
1
1
1
2
1
1
1
DESCRIPTION
0.1碌F
鹵10%
10V ceramic
capacitors
0.033碌F
鹵10%
10V ceramic
capacitors
33碌F tantalum capacitor
2.2碌F
鹵10%
10V ceramic
capacitor
SMA connectors (edge mount)
EFJohnson 142-0701-801
3-pin headers (0.1in centers)
Shunts
2-pin headers (0.1in centers)
56nH SMD inductors
Red T1 packages
150鈩?/div>
鹵1%
resistors
100鈩?/div>
鹵1%
resistor
1k鈩?potentiometer
200鈩?potentiometer
MAX3822ECM 48-pin TQFP
Test points
MAX3822 evaluation circuit
board, Rev C
MAX3822 data sheet
MAX3822 EV kit data sheet
SUPPLIER
Coilcraft
Sprague
PART
MAX3822EVKIT
Ordering Information
TEMP. RANGE
0擄C to +85擄C
IC PACKAGE
48 TQFP
*Exposed
pad
Component Suppliers
PHONE
847-639-6400
207-324-4140
FAX
847-639-1469
603-224-1430
Note:
Please indicate that you are using the MAX3822 EV kit
when contacting these component suppliers.
Quick Start
1) Set the channel-select (CS) pin to enable channel
1 by removing the shunt from J9.
2) Set the threshold level to mid-range by adjusting
threshold control potentiometers R7 and R8 for
650鈩?measured between VTH and ground.
3) Enable the
LOP
and
LOP1
indicators by placing
shunts across the LED side of J22 and J18.
4) Ensure shunts on J23 and J24 are in place.
5) Connect ground and a +3.3V supply to the proper
terminals on the EV kit.
6) Connect the inputs of channel 1 to a 50鈩?source
using 50鈩?SMA cables. Set the source to produce
a differential 50mVp-p 2.5Gbps signal.
7) Connect the outputs of channel 1 to a 50鈩?oscillo-
scope with 50鈩?SMA cables.
8) Power up the EV kit.
9) Check that the amplified and limited input pattern
is present on the output.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
