19-2821; Rev 0; 4/03
MAX3804 Evaluation Kit
General Description
The MAX3804 DC-coupled evaluation kit (EV kit) simpli-
fies evaluation of the MAX3804 12.5Gbps settable
equalizer. The EV kit enables full testing of the device
functions including all equalization settings. SMA con-
nectors with 50鈩?controlled-impedance transmission
lines to the MAX3804 are provided for all CML input
and output ports.
Features
o
DC-Coupled Evaluation Kit
o
SMA Connectors for All High-Speed Inputs and
Outputs
o
Fully Assembled and Tested
Evaluates: MAX3804
Quick Start
Note:
The MAX3804 EV kit is a DC-coupled evaluation
board. Care must be taken to ensure that no
direct short between the supply voltage and sup-
ply ground exists. Use external coupling capaci-
tors on the input and output when AC-coupling is
desired. DC-coupled operation with positive V
CC
supplies normally causes permanent damage to
laboratory test equipment (typical oscilloscope,
BERT). The MAX3804 EV kit must be operated
from a negative V
EE
supply when DC-coupled to
normal laboratory equipment.
1) Connect a -3.3V power supply to TP3 (V
EE
).
Connect the power-supply ground to TP2 (GND)
and J6 (V
CC
). Install shunts in JP2 and JP3, and
remove shunt from JP1.
2) Install shunts across pins 2 and 3 of JPEQ1, JPEQ2,
and JPEQ3 for minimal equalization (0, 0, 0). See
Table 1 for the relationship between nominal path
loss and FR-4 microstrip path length.
3) Apply a differential input signal (400mV
P-P
to
1200mV
P-P
) between SMA connectors J1 and J2
(SDI+ and SDI-).
4) Attach a differential high-speed oscilloscope with a
50鈩?input to SMA connectors J3 and J4 (SDO+ and
SDO-) to observe the output of the equalizer.
Ordering Information
PART
MAX3804EVKIT
TEMP RANGE
-40擄C to +85擄C
IC PACKAGE
16 QFN
Component List
DESIGNATION QTY
C1鈥揅5
C6
C7鈥揅10
J1鈥揓4
JP1, JP2, JP3
JPEQ1,
JPEQ2, JPEQ3
R3
R4
R5
GND, V
CC
,
V
CC1
, V
CC2
,
V
EE
, TP4, TP5
U1
None
None
None
5
1
4
4
3
3
1
1
1
7
1
5
1
1
DESCRIPTION
0.1碌F 鹵10% ceramic capacitors (0402)
0.1碌F 鹵10% ceramic capacitor (0603)
33碌F 鹵10% tantalum capacitors (case-B)
SMA connectors, tab contact
2-pin headers, 0.1in centers
3-pin headers, 0.1in centers
10k鈩?resistor (0402)
12k鈩?resistor (0402)
8k鈩?resistor (0402)
Test points
MAX3804ETE
Shunts
MAX3804 EV board
MAX3804 data sheet
Table 1. Relationship Between Nominal Path
Loss and FR-4 Microstrip Path Length
JPEQ3
0
JPEQ2 JPEQ1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
NOMINAL 6-mil FR-4
MICROSTRIP LENGTH (in)
2
6
10
14
18
22
26
30
Component Suppliers
SUPPLIER
AVX
Coilcraft
Murata
Zetex
PHONE
803-946-0690
847-639-6400
814-237-1431
516-543-7100
FAX
803-626-3123
847-639-1469
814-238-0490
516-864-7630
0
0
0
1
1
1
1
Note:
0 refers to pins 2 and 3 shunted.
1 refers to pins 1 and 2 shunted.
