19-1941; Rev 0; 4/01
鹵15kV ESD-Protected, Isolated, 3.3V
RS-485/RS-422 Data Interfaces
General Description
The MAX3480EA/MAX3480EB are electrically isolated
RS-485/RS-422 data-communications interfaces. The
RS-485/RS-422 I/O pins are protected against 鹵15kV
electrostatic discharge (ESD) shocks, without latchup.
Transceivers, optocouplers, and a transformer are all
included in one low-cost, 28-pin DIP package. A single
+3.3V supply on the logic side powers both sides of the
interface.
The MAX3480EB features reduced-slew-rate drivers
that minimize EMI and reduce reflections caused by
improperly terminated cables, allowing error-free data
transmission at data rates up to 160kbps. The
MAX3480EA鈥檚 driver slew rate is not limited, allowing
transmission rates up to 2.5Mbps.
Drivers are short-circuit current limited and are protect-
ed against excessive power dissipation by thermal
shutdown circuitry that places the driver outputs into a
high-impedance state. The receiver input has a fail-safe
feature that guarantees a logic-high output if the input
is open circuit.
The MAX3480EA/MAX3480EB are guaranteed to with-
stand 1260V
RMS
(1min) or 1520V
RMS
(1s). Their isolated
inputs and outputs meet RS-485/RS-422 specifications.
____________________________Features
o
Isolated Data Interface Guaranteed to 1260V
RMS
(1min)
o
鹵15kV ESD Protection for I/O Pins
o
Slew-Rate-Limited Data Transmission (160kbps for
MAX3480EB)
o
High-Speed, Isolated, 2.5Mbps RS-485 Interface
(MAX3480EA)
o
Single +3.3V Supply
o
Current Limiting and Thermal Shutdown for
Driver Overload Protection
o
Standard 28-Pin DIP Package
o
Allows Up to 128 Transceivers on the Bus
MAX3480EA/MAX3480EB
Pin Configuration
TOP VIEW
MAX3480EA
MAX3480EB
V
CC1
1
V
CC2
D1
D2
GND1
FS
SD
V
CC3
DI
2
3
4
5
6
7
8
9
MAX845
MAX485E
MAX487E
28 AC1
27 AC2
26 ISO V
CC1
25 B
24 ISO RO DRV
23 A
22 ISO DI IN
21 ISO DE IN
20 ISO COM1
19 ISO DI DRV
18 ISO V
CC2
17 ISO DE DRV
16 ISO COM2
15 ISO RO LED
________________________Applications
Isolated RS-485/RS-422 Data Interface
Transceivers for EMI-Sensitive Applications
Industrial-Control Local Area Networks
Automatic Test Equipment
HVAC/Building Control Networks
Telecom
Ordering Information
PART
MAX3480EACPI
MAX3480EAEPI
MAX3480EBCPI
MAX3480EBEPI
TEMP.
RANGE
PIN-
PACKAGE*
DATA
RATE
(kbps)
2500
2500
250
250
0擄C to +70擄C 28 Plastic DIP
-40擄C to +85擄C 28 Plastic DIP
0擄C to +70擄C 28 Plastic DIP
-40擄C to +85擄C 28 Plastic DIP
V
CC4
10
DE 11
GND2 12
RO 13
V
CC5
14
*See Reliability section at end of data sheet.
ISOLATION BARRIER
DIP
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
