19-2127; Rev 1; 6/02
鹵15kV ESD-Protected USB Level Translators in
UCSP
General Description
The MAX3340E/MAX3343E bidirectional level transla-
tors convert logic-level signals to USB signals, and USB
signals to logic-level signals. They include the 1.5k鈩?/div>
USB termination resistor internally, and support both
full-speed (12Mbps) and low-speed (1.5Mbps) USB
operation. They have built-in 鹵15kV ESD protection cir-
cuitry to guard the USB I/O pins, D+ and D-.
The MAX3340E/MAX3343E operate with V
L
at voltages
as low as 1.8V, ensuring compatibility with low-voltage
ASICs. The MAX3340E/MAX3343E feature a logic-
selectable suspend mode that lowers current draw to
less than 200碌A(chǔ). The MAX3340E/MAX3343E have a
unique re-enumerate feature that allows changes in
USB communication protocol while the power is on. The
MAX3340E/MAX3343E are fully compliant with USB
specification 1.1, and the full-speed and low-speed
operation under USB specification 2.0.
The MAX3340E/MAX3343E are available in the minia-
ture 4 x 4 chip-scale package, as well as the small 14-
pin TSSOP, and are rated for the -40擄C to +85擄C
extended temperature range.
Features
o
鹵15kV ESD Protection on D+ and D-
o
Internal Linear Regulator Allows Direct Powering
from the USB
o
Internal 1.5k鈩?Termination Resistor for Low/Full-
Speed
o
Support Low-Speed and Full-Speed USB
Communications
o
Comply with USB Standard 1.1
o
Three-State Outputs
o
Re-Enumerate with Power Applied
o
Up to 15mA Available from the +3.3V Linear
Regulator to Power External Circuitry
o
No Power-Supply Sequencing Required
o
Operate with V
L
of 1.8V to 3.6V, Ensuring
Compatibility with Low-Voltage ASICs
o
Available in Miniature Chip-Scale Package
MAX3340E/MAX3343E
Applications
Cell Phones
PC Peripherals
Data Cradles
PDAs
MP3 Players
PART
MAX3340EEUD
MAX3340EEBE-T*
MAX3343EEUD
MAX3343EEBE-T*
Ordering Information
TEMP RANGE
-40擄C to +85擄C
-40擄C to +85擄C
-40擄C to +85擄C
-40擄C to +85擄C
PIN-PACKAGE
14 TSSOP
16 UCSP**
14 TSSOP
16 UCSP**
*Future
product鈥攃ontact factory for availability.
**UCSP
reliability is integrally linked to the user鈥檚 assembly
methods, circuit board material, and environment. Refer to the
UCSP Reliability Notice in the UCSP Reliability section of this
data sheet for more information.
Pin Configurations
TOP VIEW
RCV 1
VP
MODE
2
3
14 V
L
13 VTRM
12 D+
D
VP
C
11 D-
10 GND
9
8
V
CC
SPEED
A
RENB SPEED
(ENUMERATE)
V
CC
GND
B
OE/
SUSP
ENUMERATE (OE)
D-
VM
MODE
D+
RCV
V
L
VTRM
BOTTOM VIEW
1
2
3
4
MAX3340E/MAX3343E
VM 4
OE/ENUMERATE (OE) 5
RENB (ENUMERATE) 6
SUSP 7
MAX3340E
MAX3343E
TSSOP
() ARE FOR MAX3343E ONLY.
UCSP
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
