19-2158; Rev 0; 9/01
MAX3271 Evaluation Kit
General Description
The MAX3271 evaluation kit (EV kit) allows complete
evaluation of the MAX3271 transimpedance amplifier.
The EV kit includes a circuit that emulates the high-
speed, zero-to-peak current input signal that would be
produced by a photodiode. The kit also includes a cali-
bration circuit that allows accurate bandwidth measure-
ment. The MAX3271 EV kit is fully assembled and tested.
o
Fully Assembled and Tested
o
Includes Photodiode Emulation Circuit
o
Calibration Circuit for Accurate Bandwidth
Measurement
Features
Evaluates: MAX3271
Component Suppliers
SUPPLIER
AVX
Coilcraft
Murata
PHONE
843-444-2863
847-639-6400
415-964-6321
FAX
843-626-3123
847-639-1469
415-964-8165
PART
MAX3271EVKIT
Ordering Information
TEMP. RANGE
-40擄C to +85擄C
IC PACKAGE
Chip-On-Board
Note:
Please indicate that you are using the MAX3271 when
contacting these component suppliers.
Component List
DESIGNATION
C1, C5, C6, C8
QTY
4
DESCRIPTION
0.01碌F
鹵10%
ceramic
capacitors (0402)
Murata GRM36X7R103K016A
0.1碌F
鹵10%
ceramic capacitors
(0402)
Murata GRM36X5R104K010AD
10碌F
鹵10%
tantalum capacitor
AVX TAJC106K010R
100pF
鹵10%
ceramic capacitor
(0402)
Murata GRM36X7R102K050AD
SMA connectors (edge-mount,
round contact)
Note:
Cut center pin to
approximately 1/16in length.
1
脳
2-pin header (0.1in centers)
56nH inductor
Coilcraft 0805HS-560XKBC
0鈩?resistors
DESIGNATION
R1A, R1B, R5A,
R5B
R3, R7
R4, R8
TP1, J4, J5
U1
Outside Vendor
to Supply
Outside Vendor
to Supply
None
None
QTY
4
2
2
3
1
0
DESCRIPTION
499鈩?/div>
鹵1%
resistors (0402)
4.99k鈩?/div>
鹵1%
resistors (0402)
49.9鈩?/div>
鹵1%
resistors (0402)
Test points
Digi-Key 5000K-ND
MAX3271E/D die
1mil Au wire (8 bonds)
American Fine Wire EL4-7 TS8
AW8
Epoxy, Ablefilm 84-1 LMI
MAX3271 EV kit circuit board
MAX3271 data sheet
C2鈥揅4, C9, C10
5
C7
1
C11
1
0
1
1
J1鈥揓3, J6, J7
5
JU1
L1
L2, L3
1
1
2
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
