19-2939; Rev 1; 9/03
5V, 1Mbps, Low Supply Current
CAN Transceivers
General Description
The MAX3058/MAX3059 interface between the con-
troller area network (CAN) protocol controller and the
physical wires of the bus lines in a CAN. They are pri-
marily intended for printer and telecom backplane appli-
cations requiring data rates up to 1Mbps. These
devices provide differential transmit capability to the bus
and differential receive capability to the CAN controller.
The MAX3058 output common-mode range is from -7V
to +12V. The MAX3059 output common-mode range is
from 0V to V
CC
. The MAX3059 contains an internal
switch termination resistor that makes it ideal for JetLink
applications.
The MAX3058 features four different modes of opera-
tion: high speed, slope control, standby, and shutdown.
The MAX3059 features three different modes of opera-
tion: high speed, slope control, and shutdown. High-
speed mode allows data rates up to 1Mbps. In
slope-control mode, the slew rate may be optimized for
data rates up to 500kbps, so the effects of EMI are
reduced, and unshielded twisted or parallel cable can
be used. In standby mode, the transmitters are shut off
and the receivers are put into low-current mode. In
shutdown mode, the transmitter and receiver are
switched off.
The MAX3058/MAX3059 are available in an 8-pin SO
package and are specified over the -40擄C to +125擄C
temperature range.
Features
o
Four Operating Modes
High-Speed Operation Up to 1Mbps
Slope-Control Mode to Reduce EMI (40kbps to
500kbps)
Low-Current Shutdown Mode
Standby Mode (MAX3058 Only)
o
Thermal Shutdown
o
Current Limiting
o
ESD Protection
鹵12kV
Human Body Model
MAX3058/MAX3059
Ordering Information
PART
MAX3058ASA
MAX3059ASA
TEMP RANGE
-40擄C to +125擄C
-40擄C to +125擄C
PIN-PACKAGE
8 SO
8 SO
Selector Guide
PART
MAX3058ASA
MAX3059ASA
TERMINATION
RESISTOR
No
Yes
STANDBY
Yes
No
Applications
Printers JetLink
Industrial Control Networks
Telecom Backplane
Consumer Applications
Pin Configurations
TOP VIEW
TXD
1
GND
2
8
7
RS
CANH
CANL
SHDN
TXD
1
GND
V
CC
2
8
7
RS
CANH
CANL
TERM
MAX3058
V
CC
3
6
5
3
RXD
4
RXD
4
MAX3059
6
5
SO
SO
Typical Operating Circuit appears at end of data sheet.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
