MAX1982 Evaluation Kit
General Description
The MAX1982 evaluation kit (EV kit) provides a regulated
1.2V output voltage while operating on input voltages
from 1.25V to 5.5V. It delivers a 0.3A output current
from a 1.25V to 2.5V input, with less than 300mV
dropout. Operation with higher input voltages (up to
5.5V) is possible as long as the maximum power dissi-
pation across the internal pass transistor is less than
727mW.
The MAX1982 EV kit is a fully assembled and tested
surface-mount printed circuit (PC) board. The board is
shipped with a fixed 1.2V output MAX1982 IC, and can
also be used to evaluate the MAX1983 (adjustable out-
put). Additional pads are provided on the board鈥檚 com-
ponent side to accommodate the external components
used with the MAX1983.
o
1.25V to 5.5V Input Supply Range
o
1.2V Fixed Output Voltage
o
Up to 0.3A Output Current
o
<5碌A(chǔ) Shutdown Supply Current
o
Power-Good (PGOOD) Open-Drain Output with
1ms Rising Edge Propagation Delay (MAX1982)
o
Surface-Mount Construction
o
Fully Assembled and Tested
Features
Evaluates: MAX1982/MAX1983
Ordering Information
PART
MAX1982EVKIT
TEMP RANGE
0擄C to +70擄C
IC PACKAGE
6 SOT23
Note:
To evaluate the MAX1983, request a MAX1983EUT free
sample with the MAX1982EVKIT.
Component List
DESIGNATION QTY
C1
1
DESCRIPTION
0.1碌F
鹵20%,
X7R ceramic capacitor
(1206)
TDK C3216X7R2A104M
10碌F
鹵20%,
X5R ceramic capacitors
(1210)
TDK C3225X7R1C106M
Not installed (0805)
3-pin header
2-pin header
DESIGNATION QTY
R1
R2, R3
U1
None
None
None
None
1
2
1
2
1
1
1
DESCRIPTION
100k鈩?/div>
鹵5%
resistor (0805)
Not installed (0805)
MAX1982EUT
(6-pin SOT23)
Top mark = ABEA
Shunts
MAX1982 PC board
MAX1982 data sheet
MAX1982 EV kit data sheet
C2, C3
C4
JU1
JU2
1
1
1
1
Component Suppliers
SUPPLIER
TDK
PHONE
847-803-6100
FAX
847-390-4405
WEBSITE
www.component.tdk.com
Note:
Please indicate that you are using the MAX1982 when contacting this component supplier.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
1
2
3
4
