10k鈩?/div>
鹵5%
resistor (0603)
MAX1951ESA 8-lead SO
Shunt
MAX1951 PC board
C1, C5
2
Ordering Information
PART
MAX1951EVKIT
TEMP RANGE
0擄C to +85擄C
IC PACKAGE
8 SO
C2
1
Note:
To evaluate MAX1952ESA, request an MAX1952ESA-18
free sample with the MAX1951EVKIT.
C3, C4
2
Quick Start
The MAX1951 EV kit is a fully assembled and tested
surface-mount board. Follow the steps below to verify
board operation.
Do not turn on the power supply
until all connections are completed.
1) Verify that there is no shunt (open) across JU1
(shutdown disabled).
2) Connect a voltmeter and load (if any) to the VOUT
pad. Connect the ground to the GND closest to
VOUT.
3) Connect a 2.6V to 5.5V power supply to the VIN
pad. Connect the power-supply ground to the
GND pad closest to VIN.
4) Turn on the power supply and verify that the output
voltage is 1.5V.
To evaluate other output voltages with the MAX1951, see
the
Evaluating Other Output Voltages
section. To evaluate
the MAX1952, see the
Evaluating the MAX1952
section.
C6
D1
JU1
0
0
1
L1
1
Q1
R1
R2
R3
R4
R5
U1
None
None
1
1
1
1
1
1
1
1
1
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
1
2
3
