19-4781; Rev 0; 5/00
MAX1710 Evaluation Kit
General Description
The MAX1710 evaluation kit (EV kit) demonstrates the
data sheet鈥檚 standard 7A notebook CPU application cir-
cuit (see MAX1710/MAX1711 data sheet). This DC-DC
converter steps down high-voltage batteries and/or AC
adapters, generating a precision, low-voltage CPU core
V
CC
rail.
The circuit was designed for a 7V to 24V battery range,
but accommodates from 4.5V to 24V. Some parameters,
such as load-transient response and maximum thermal
load capability, may be degraded by going outside the
7V to 24V range. The continuous output current rating,
based on worst-case MOSFET R
DS(ON)
, heat sinking,
and other thermal stress issues, is 5.5A at T
A
= +70擄C.
This EV kit is a fully assembled and tested circuit
board. It also allows the evaluation of the MAX1711.
Features
o
High Speed, Accuracy, and Efficiency
o
Fast-Response QUICK-PWM鈩?Architecture
o
7V to 24V Input Voltage Range
o
1.25V to 2V Output Voltage Range
o
7A Peak Load-Current Capability
(5.5A Continuous)
o
93% Efficient (V
OUT
= 2V, V
BATT
= 7V,
I
LOAD
= 4A)
o
300kHz Switching Frequency
o
No Current-Sense Resistor
o
Remote GND and V
OUT
Sensing
o
Power-Good Output
o
24-Pin QSOP Package
o
Low-Profile Components
o
Fully Assembled and Tested
Evaluates: MAX1710/MAX1711
Ordering Information
PART
MAX1710EVKIT
TEMP. RANGE
0擄C to +70擄C
IC PACKAGE
24 QSOP
NOTE:
To evaluate the MAX1711, request a MAX1711EEG
free sample with the MAX1710 EV Kit.
Component List
DESIGNATION QTY
C1鈥揅4
4
DESCRIPTION
4.7碌F, 25V ceramic capacitors
Taiyo Yuden TMK325BJ475K
D3
C1鈥揅4
(ALTERNATE)
4
10碌F, 25V ceramic capacitors
Tokin C34Y5U1E106Z or
United Chemi Con/Marcon
THCR50E1E106ZT
470碌F, 6.3V, 30m鈩?low-ESR tantalum
capacitors
Kemet T510X477M006AS
10碌F, 6.3V ceramic capacitor
Taiyo Yuden JMK325BJ106MN or
TDK C3225X5R1A106M
0.1碌F ceramic capacitor
0.22碌F ceramic capacitors
470pF ceramic capacitor
1碌F ceramic capacitor
Not installed
2A Schottky diode
SGS-Thomson STPS2L25U or
Nihon EC31QS03L
100mA Schottky diode
Central Semiconductor CMPSH-3
Hitachi HRB0103A
N2
1
N1
1
1
DESIGNATION QTY
DESCRIPTION
1A Schottky diode
Motorola MBRS130LT3,
Nihon EC10QS03, or
International Rectifier 10BQ040
Hitachi HRF22
200mV switching diode
Central Semiconductor CMPD2838
2碌H power inductor
Panasonic ETQP6F2R0HFA,
Coiltronics UP4B-2R2, or
Coilcraft DO5022P-222HC
N-channel MOSFET
International Rectifier IRF7807,
Fairchild FDS6612A, or
Siliconix Si4416DY
N-channel MOSFET
International Rectifier IRF7805,or
Fairchild FDS6670A, or
NEC uPA1706, or
Hitachi HAT2040R
20鈩?鹵5% resistor
D4
1
C5, C6, C7
3
L1
1
C8
C9
C11, C12
C14
C15
C16, C17, C18
D1
1
1
2
1
1
0
1
R1
1
QUICK-PWM is a trademark of Maxim Integrated Products.
D2
1
________________________________________________________________
Maxim Integrated Products
1
For free samples & the latest literature: http://www.maxim-ic.com, or phone 1-800-998-8800
For small orders, phone 1-800-835-8769.
