19-2700; Rev 0; 12/02
MAX1534 Evaluation Kit
General Description
The MAX1534 evaluation kit (EV kit) is a fully assembled
and tested surface-mount circuit board that demon-
strates the MAX1534 triple-output keep-alive power sup-
ply IC. The MAX1534 integrates one high-performance
step-down converter and two low-dropout regulators
(LDOs). The step-down converter is configured for 5.0V
and provides up to 500mA. The first and second LDOs
are configured for 3.3V and 1.8V at currents up to
160mA each. Power management functions include an
accurate shutdown input and power-OK (POK) output.
The EV kit also allows for adjustable output voltages by
including extra pads for feedback resistors.
o
Triple-Output Power Supply
5.0V at 500mA (typ)
3.3V at 160mA
1.8V at 160mA
o
Integrated Power MOSFETs
o
4.5V to 24V Input Supply Range
o
Adjustable Inductor Current Limit
o
Fixed or Adjustable Outputs
o
Power-OK (POK) Output
o
3.5碌A(chǔ) Shutdown Supply Current (typ)
o
Surface-Mount Construction
o
Fully Assembled and Tested
Features
Evaluates: MAX1534
Ordering Information
PART
MAX1534EVKIT
TEMP RANGE IC PACKAGE
0擄C to +70擄C
16 Thin QFN 4mm
脳
4mm
Component List
DESIGNATION
C1
QTY
1
DESCRIPTION
10碌F 鹵20%, 25V X7R ceramic
capacitor (1812)
TDK C4532X7R1E106M
47碌F 鹵20%, 6.3V X5R ceramic
capacitor (1210)
TDK C3225X5R0J476M
2.2碌F 鹵20%, 10V X5R ceramic
capacitors (0805)
TDK C2012X5R1A225M
0.01碌F 鹵20%, 25V X7R ceramic
capacitor (0402)
TDK C1005X7R1E103M
1A, 30V, Schottky diode (SMA)
Nihon EP10QY03
DESIGNATION
L1
R1鈥揜6
R7
R8, R9
R10, R11
JU1, JU2
JU3
JU4
U1
None
None
QTY
1
0
1
0
0
2
0
1
1
3
1
DESCRIPTION
15碌H, 1A inductor
Sumida CDRH6D38-150
Not installed (0603)
100k鈩?鹵5% resistor (0603)
Not installed (2010)
Not installed (0805)
Jumpers, SIP-3, 3-pin headers (SIP-3)
Not installed (SIP-3)
Jumper, 2
脳
3 pin header
MAX1534ETE (16-pin thin QFN)
Shunts
MAX1534 PC board
C2
1
C3, C5, C6
3
C4
1
D1
1
Component Suppliers
SUPPLIER
Nihon
Sumida
TDK
PHONE
81-33343-3411
847-545-6700
847-803-6100
FAX
81-33342-5407
847-545-6720
847-390-4405
WEBSITE
www.niec.co.jp
www.sumida.com
www.component.tdk.com
Note:
Please indicate that you are using the MAX1534 when contacting these component suppliers.
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
