19-2054; Rev 2; 7/02
MAX1181 Evaluation Kit
General Description
The MAX1181 Evaluation kit (EV Kit) is a fully assembled
and tested circuit board that contains all the components
necessary to evaluate the performance of the nonmulti-
plexed MAX1180鈥揗AX1184 and MAX1190 or multiplexed
MAX1185 and MAX1186, dual 10-bit analog-to-digital
converters (ADC). The MAX1180鈥揗AX1186 and
MAX1190 accept differential or single-ended analog
inputs and the EV kit allows for evaluation of each ADC
with both types of signals from one single-ended analog
signal. The digital output produced by the ADC can easily
be sampled with a user-provided high-speed logic ana-
lyzer or data-acquisition system. The EV kit operates from
3.0V analog and 2.0V digital power supplies. It includes
circuitry that generates a clock signal from an AC signal
provided by the user. The EV kit comes with the MAX1181
installed. Order free samples of the pin-compatible
MAX1180, MAX1182, MAX1183, MAX1184, MAX1185,
MAX1186, or MAX1190 to evaluate these parts.
o
Low Voltage and Power Operation
o
Single-Ended or Fully Differential Signal Input
Configuration
o
Clock-Shaping Circuit
o
Fully Assembled and Tested
o
Supports Both Nonmultiplexed
(MAX1180鈥揗AX1184/MAX1190)
and Multiplexed (MAX1185/MAX1186)
Output Operation
Features
o
Up to 80Msps Sampling Rate (MAX1181)
Evaluates: MAX1180鈥揗AX1186/MAX1190
Ordering Information
PART
MAX1181EVKIT
TEMP RANGE
0擄C to +70擄C
IC PACKAGE
48 TQFP-EP
Selector Guide
PART
MAX1190ECM
MAX1180ECM
MAX1181ECM
MAX1182ECM
MAX1183ECM
MAX1184ECM
MAX1185ECM
MAX1186ECM
SPEED (Msps)
120
105
80
65
40
20
20, multiplexed
40, multiplexed
Component List
DESIGNATION
C1鈥揅5, C7, C9,
C11, C16鈥揅19,
C21, C23, C27,
C31, C33, C34,
C36鈥揅39,
C42鈥揅49, C51, C52
C24, C25,
C28, C29
C8, C10, C20,
C22, C26, C32,
C35, C40, C41
QTY
DESCRIPTION
0.1碌F, 16V, X7R, 鹵10% ceramic
capacitors (0603)
Taiyo Yuden EMK107BJ104KA or
TDK C1608X7R1E104KT
22pF, 50V, 鹵5% ceramic
capacitors (0603)
TDK C1608CCOG1H220JT
2.2碌F, 10V tantalum capacitors (A)
AVX TAJA225K010 or Kemet
T494A225K010AS
1000pF, 50V 鹵10% ceramic
capacitor (0603)
TDK C1608X7R1H102KT
DESIGNATION
C12鈥揅15
C6, C50
R1, R6, R19
R31鈥揜33
4
R7
R38
R2鈥揜5, R35,
R51鈥揜71
R15鈥揜18
R8, R21鈥揜30,
R41鈥揜50
QTY
4
0
0
0
1
1
26
4
21
DESCRIPTION
10碌F, 10V, tantalum capacitors (B)
AVX TAJB106M010 or Kemet
T494B106K010AS
Not installed (0603)
Not installed (0603)
Not installed (0805)
0鈩?鹵5% resistor (0603)
3.9鈩?鹵5% resistor (0805)
49.9鈩?鹵1% resistors (0603)
24.9鈩?鹵1% resistors (0603)
100鈩?鹵1% resistors (0603)
32
9
C30
1
Component List continued on next page.
1
________________________________________________________________
Maxim Integrated Products
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim鈥檚 website at www.maxim-ic.com.
