M74HC153TTR Datasheet

  • M74HC153TTR

  • IC MULTIPLEXER DUAL 4CH 16-TSSOP

  • 521.70KB

  • 10頁

  • STMicroelectronics   STMicroelectronics

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

M74HC153
DUAL 4 CHANNEL MULTIPLEXER
s
s
s
s
s
s
s
HIGH SPEED:
t
PD
= 16ns (TYP.) at V
CC
= 6V
LOW POWER DISSIPATION:
I
CC
= 4碌A(chǔ)(MAX.) at T
A
=25擄C
HIGH NOISE IMMUNITY:
V
NIH
= V
NIL
= 28 % V
CC
(MIN.)
SYMMETRICAL OUTPUT IMPEDANCE:
|I
OH
| = I
OL
= 4mA (MIN)
BALANCED PROPAGATION DELAYS:
t
PLH
鈮?/div>
t
PHL
WIDE OPERATING VOLTAGE RANGE:
V
CC
(OPR) = 2V to 6V
PIN AND FUNCTION COMPATIBLE WITH
74 SERIES 153
DIP
SOP
TSSOP
ORDER CODES
PACKAGE
DIP
SOP
TSSOP
TUBE
M74HC153B1R
M74HC153M1R
T&R
M74HC153RM13TR
M74HC153TTR
DESCRIPTION
The M74HC153 is an high speed CMOS DUAL 4
CHANNEL MULTIPLEXER fabricated with silicon
gate C
2
MOS technology.
Each of these data (1C0-1C3, 2C0-2C3) is
selected by the two address inputs A and B.
Separate strobe inputs (1G, 2G) are provided for
each of the two four-line sections. The strobe input
(nG) can be used to inhibit the data output; the
output of M74HC153 is fixed at low level while the
strobe input is held high.
All inputs are equipped with protection circuits
against static discharge and transient excess
voltage.
PIN CONNECTION AND IEC LOGIC SYMBOLS
July 2001
1/10

M74HC153TTR 產品屬性

  • M74HC153 View All Specifications

  • 2,500

  • 集成電路 (IC)

  • 邏輯 - 信號開關，多路復用器，解碼器

  • 74HC

  • 多路復用器

  • 2 x 4:1

  • 1

  • 5.2mA，5.2mA

  • 單電源

  • 2 V ~ 6 V

  • -55°C ~ 125°C

  • 表面貼裝

  • 16-TSSOP（0.173"，4.40mm 寬）

  • 16-TSSOP

  • 帶卷 (TR)
