M36L0T7050 Datasheet

  • M36L0T7050

  • 128 Mbit (Multiple Bank, Multi-Level, Burst) Flash Memory 32...

  • 18頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

M36L0R7050T0
M36L0R7050B0
128 Mbit (Multiple Bank, Multi-Level, Burst) Flash Memory
32 Mbit (2M x16) PSRAM, 1.8V Supply Multi-Chip Package
FEATURES SUMMARY
MULTI-CHIP PACKAGE
鈥?1 die of 128 Mbit (8Mb x16, Multiple Bank,
Multi-level, Burst) Flash Memory
鈥?1 die of 32 Mbit (2Mb x16) Asynchronous
Pseudo SRAM
鈻?/div>
SUPPLY VOLTAGE
鈥?V
DDF
= V
DDP
= V
DDQ
= 1.7 to 1.95V
鈥?V
PPF
= 9V for fast program (12V tolerant)
鈻?/div>
ELECTRONIC SIGNATURE
鈥?Manufacturer Code: 20h
鈥?Device Code (Top Flash Configuration)
M36L0R7050T0: 88C4h
鈥?Device Code (Bottom Flash
Configuration) M36L0R7050B0: 88C5h
鈻?/div>
PACKAGE
鈥?Compliant with Lead-Free Soldering
Processes
鈥?Lead-Free Versions
FLASH MEMORY
鈻?/div>
SYNCHRONOUS / ASYNCHRONOUS READ
鈥?Synchronous Burst Read mode: 54MHz
鈥?Asynchronous Page Read mode
鈥?Random Access: 85ns
鈻?/div>
SYNCHRONOUS BURST READ SUSPEND
鈻?/div>
PROGRAMMING TIME
鈥?10碌s typical Word program time using
Buffer Program
鈻?/div>
MEMORY ORGANIZATION
鈥?Multiple Bank Memory Array: 8 Mbit
Banks
鈥?Parameter Blocks (Top or Bottom
location)
鈻?/div>
DUAL OPERATIONS
鈥?program/erase in one Bank while read in
others
鈥?No delay between read and write
operations
鈻?/div>
SECURITY
鈥?64 bit unique device number
鈥?2112 bit user programmable OTP Cells
鈻?/div>
Figure 1. Package
FBGA
TFBGA88 (ZAQ)
8 x 10mm
BLOCK LOCKING
鈥?All blocks locked at power-up
鈥?Any combination of blocks can be locked
with zero latency
鈥?WP
F
for Block Lock-Down
鈥?Absolute Write Protection with V
PPF
= V
SS
鈻?/div>
COMMON FLASH INTERFACE (CFI)
鈻?/div>
100,000 PROGRAM/ERASE CYCLES per
BLOCK
PSRAM
鈻?/div>
ACCESS TIME: 85ns
鈻?/div>
LOW STANDBY CURRENT: 100碌A(chǔ)
鈻?/div>
DEEP POWER-DOWN CURRENT: 10碌A(chǔ)
鈻?/div>
BYTE CONTROL: UB
P
/LB
P
鈻?/div>
PROGRAMMABLE PARTIAL ARRAY
鈻?/div>
8 WORD PAGE ACCESS CAPABILITY: 25ns
鈻?/div>
PARTIAL POWER-DOWN MODES
鈥?Deep Power-Down
鈥?4 Mbit Partial Power-Down
鈥?8 Mbit Partial Power-Down
鈥?16 Mbit Partial Power-Down
鈻?/div>
December 2004
1/18
