M2732A Datasheet

  • M2732A

  • NMOS 32K 4K x 8 UV EPROM

  • 9頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

M2732A
NMOS 32K (4K x 8) UV EPROM
FAST ACCESS TIME: 200ns
EXTENDED TEMPERATURE RANGE
SINGLE 5V SUPPLY VOLTAGE
LOW STANDBY CURRENT: 35mA max
INPUTS and OUTPUTS TTL COMPATIBLE
DURING READ and PROGRAM
COMPLETELY STATIC
24
1
FDIP24W (F)
DESCRIPTION
The M2732A is a 32,768 bit UV erasable and
electrically programmable memory EPROM. It is
organized as 4,096 words by 8 bits. The M2732A
with its single 5V power supply and with an access
time of 200 ns, is ideal suited for applications where
fast turn around and pattern experimentation one
important requirements.
The M2732A is honsed in a 24 pin Window Ceramic
Frit-Seal Dual-in-Line package. The transparent lid
allows the user to expose the chip to ultraviolet light
to erase the bit pattern. A new pattern can be then
written to the clerice by following the programming
procedure.
Figure 1. Logic Diagram
VCC
12
A0-A11
8
Q0-Q7
E
M2732A
Table 1. Signal Names
A0 - A11
Q0 - Q7
E
GV
PP
V
CC
V
SS
Address Inputs
Data Outputs
Chip Enable
Output Enable / Program Supply
Supply Voltage
Ground
GVPP
VSS
AI00780B
July 1994
1/9
