M25PXX

512 Kbit to 32 Mbit, Low Voltage, Serial Flash Memory

With 40 MHz or 50 MHz SPI Bus Interface

DATA BRIEF

FEATURES SUMMARY

鈻?/div>

512Kbit to 32Mbit of Flash Memory

Page Program (up to 256 Bytes) in 1.4ms

(typical)

Sector Erase (256 Kbit or 512Kbit)

Bulk Erase (512Kbit to 32Mbit)

2.7 to 3.6V Single Supply Voltage

SPI Bus Compatible Serial Interface

40MHz to 50MHz Clock Rate (maximum)

Deep Power-down Mode 1碌A(chǔ) (typical)

Electronic Signatures

鈥?JEDEC Standard Two-Byte Signature

(20xxh)

鈥?RES Instruction, One-Byte, Signature, for

backward compatibility

More than 100000 Erase/Program Cycles per

Sector

More than 20 Year Data Retention

Figure 1. Packages

VDFPN8 (ME)

8x6mm (MLP8)

VDFPN8 (MP)

(MLP8)

Table 1. Product List

Reference

Part Number

M25P32

M25P16

M25P80

M25Pxx

M25P40

M25P20

M25P10-A

M25P05-A

SO16 (MF)

300 mil width

SO8 (MN)

150 mil width

October 2004

For further information contact your local ST sales office.

1/7
