ESMT

Revision History

Revision 0.1 (May. 13 2005)

-Original

Revision 0.2 (Aug. 08 2005)

-Delete Non-Pb-free of ordering information

-Modify typing error of Pin Arrangement

Revision 1.0 (Mar. 08 2006)

-Delete 鈥淧reliminary鈥?at every page

-Modify tWR from 2clk to 15ns

-Modify tWTR from 1clk to 2ns

Revision 1.1 (Oct. 25 2006)

-Add -4BG spec (only for CL4)

Revision 1.2 (Nov. 16 2006)

-Add 100 pin LQFP package

Revision 1.3 (Mar. 02 2007)

-Delete BGA ball name of packing dimensions

Revision 1.4 (Mar. 12 2007)

-Add -3.6 speed grade

Revision 1.5 (Mar. 21 2007)

-Add -4(CL3) specification

Revision 1.6 (Mar. 29 2007)

- Modify A10 to A8 on P26

- Modify the figure on P37

Revision 1.7 (Apr. 17 2007)

- Modify -4(CL3) VDD; VDDQ; spec

Revision 1.8 (May. 2 2007)

- Modify P

D

spec

M13S128324A

Elite Semiconductor Memory Technology Inc.

Publication Date : May. 2007

Revision : 1.8

1/49
