LZ9FD34

LZ9FD34

DESCRIPTION

The LZ9FD34 is a CMOS single-chip driver IC which

generates timing pulses for driving 270 k/320 k/

410 k/470 k-pixel B/W CCD area sensors, syn-

chronous pulses for TV signals and processing for

video signals.

Single-chip Driver IC for 270 k/320 k/

410 k/470 k-pixel B/W CCDs

PIN CONNECTIONS

48-PIN QFP

TOP VIEW

48 47 46 45 44 43 42 41 40 39 38 37

TST

1

1

TST

2

2

VRI 3

TVMD 4

CSYN 5

V

DD

6

GND 7

CBLK 8

HD 9

VD 10

HBLK 11

TST

3

12

13 14 15 16 17 18 19 20 21 22 23 24

BCP

TST

4

TST

5

GND

ACLX

V

DD

FLMD

EEMD

EEUD

EENR

FCDS

FS

36 OFDX

35 VH

3X

34 VH

1X

33 V

4X

32 V

3X

31 GND

30 V

DD

29 V

2X

28 V

1X

27 TST

7

26 CCD

25 TST

6

FEATURES

鈥?Designed for B/W CCD area sensors with 270 k/

320 k/410 k/470 k-pixel

鈥?Switchable between EIA and CCIR modes

鈥?Electronic shutter and EE control are possible

鈥?Maximum shutter speed is 1/100 000 s

鈥?Flicker-less function

鈥?Non-interlace mode is possible

鈥?External synchronization is possible

鈥?Single +5 V power supply

鈥?Field accumulation mode and frame accumu-

lation mode are possible

鈥?Package :

48-pin QFP (QFP048-P-0707) 0.5 mm pin-pitch

In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP devices shown in

catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.

1

NINT

OSCO

OSCI

V

DD

FH

1

GND

FH

2

V

DD

FR

WIND

EEST

ITCH

(QFP048-P-0707)
