LTC3405AES6 Datasheet

  • LTC3405AES6

  • Analog IC

  • 240.92KB

  • 16頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

LTC3405A
1.5MHz, 300mA
Synchronous Step-Down
Regulator in ThinSOT
FEATURES
s
s
DESCRIPTIO
s
s
s
s
s
s
s
s
s
s
s
s
High Efficiency: Up to 96%
Very Low Quiescent Current: Only 20
碌
A
During Operation
300mA Output Current at V
IN
= 3V
2.5V to 5.5V Input Voltage Range
1.5MHz Constant Frequency Operation
No Schottky Diode Required
Low Dropout Operation: 100% Duty Cycle
Stable with Ceramic Capacitors
0.8V Reference Allows Low Output Voltages
Shutdown Mode Draws < 1碌A(chǔ) Supply Current
鹵2%
Output Voltage Accuracy
Current Mode Operation for Excellent Line and
Load Transient Response
Overtemperature Protected
Low Profile (1mm) ThinSOT
TM
Package
The LTC
廬
3405A is a high efficiency monolithic synchro-
nous buck regulator using a constant frequency, current
mode architecture. Supply current during operation is
only 20碌A(chǔ) and drops to <1碌A(chǔ) in shutdown. The 2.5V to
5.5V input voltage range makes the LTC3405A ideally
suited for single Li-Ion battery-powered applications. 100%
duty cycle provides low dropout operation, extending
battery life in portable systems.
Switching frequency is internally set at 1.5MHz, allowing
the use of small surface mount inductors and capacitors.
The LTC3405A is specifically designed to work well with
ceramic output capacitors, achieving very low output
voltage ripple and a small PCB footprint.
The internal synchronous switch increases efficiency and
eliminates the need for an external Schottky diode. Low
output voltages are easily supported with the 0.8V feed-
back reference voltage. The LTC3405A is available in a low
profile (1mm) ThinSOT package.
For fixed 1.5V and 1.8V output versions, refer to the
LTC3405A-1.5/LTC3405A-1.8 data sheet.
, LTC and LT are registered trademarks of Linear Technology Corporation.
ThinSOT is a trademark of Linear Technology Corporation.
APPLICATIO S
s
s
s
s
s
s
Cellular Telephones
Personal Information Appliances
Wireless and DSL Modems
Digital Still Cameras
MP3 Players
Portable Instruments
TYPICAL APPLICATIO
V
IN
2.7V
TO 5.5V
4
C
IN
鈥?/div>
2.2碌F
CER
V
IN
RUN
MODE
GND
2
V
FB
5
SW
3
LTC3405A
1
6
100
95
V
IN
= 3.6V
4.7碌H**
22pF
EFFICIENCY (%)
V
OUT
*
3.3V
C
OUT
鈥犫€?/div>
4.7碌F
CER
90
85
80
75
V
IN
= 5.5V
70
65
60
0.1
V
IN
= 4.2V
887k
280k
3405A F01a
*V
OUT
CONNECTED TO V
IN
FOR 2.7V < V
IN
< 3.3V
**MURATA LQH3C4R7M34
鈥?/div>
TAIYO YUDEN LMK212BJ225MG
鈥犫€?/div>
TAIYO YUDEN JMK212BJ475MG
Figure 1a. High Efficiency Step-Down Converter
Figure 1b. Efficiency vs Load Current
3405af
U
1
100
10
OUTPUT CURRENT (mA)
1000
3405A F01b
U
U
1
