LT1354CS8 Datasheet

  • LT1354CS8

  • 12MHz, 400V/us Op Amp

  • 12頁

  • LINER

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

LT1354
12MHz, 400V/碌s Op Amp
FEATURES
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
DESCRIPTION
The LT
廬
1354 is a low power, high speed, high slew rate
operational amplifier with outstanding AC and DC perfor-
mance. The LT1354 has much lower supply current, lower
input offset voltage, lower input bias current, and higher
DC gain than devices with comparable bandwidth. The
circuit topology is a voltage feedback amplifier with the
slewing characteristics of a current feedback amplifier.
The amplifier is a single gain stage with outstanding
settling characteristics which makes the circuit an ideal
choice for data acquisition systems. The output drives a
500鈩?load to
鹵12V
with
鹵15V
supplies and a 150鈩?load
to
鹵2.5V
on
鹵5V
supplies. The amplifier is also stable with
any capacitive load which makes it useful in buffer or cable
driver applications.
The LT1354 is a member of a family of fast, high perfor-
mance amplifiers using this unique topology and employ-
ing Linear Technology Corporation鈥檚 advanced bipolar
complementary processing. For dual and quad amplifier
versions of the LT1354 see the LT1355/LT1356 data
sheet. For higher bandwidth devices with higher supply
current see the LT1357 through LT1365 data sheets.
Singles, duals, and quads of each amplifier are available.
, LTC and LT are registered trademarks of Linear Technology Corporation.
C-Load is a trademark of Linear Technology Corporation
12MHz Gain-Bandwidth
400V/碌s Slew Rate
1.25mA Maximum Supply Current
Unity Gain Stable
C-Load
TM
Op Amp Drives All Capacitive Loads
10nV/鈭欻z Input Noise Voltage
800碌V Maximum Input Offset Voltage
300nA Maximum Input Bias Current
70nA Maximum Input Offset Current
12V/mV Minimum DC Gain, R
L
=1k
230ns Settling Time to 0.1%, 10V Step
280ns Settling Time to 0.01%, 10V Step
鹵12V
Minimum Output Swing into 500鈩?/div>
鹵2.5V
Minimum Output Swing into 150鈩?/div>
Specified at
鹵2.5V, 鹵5V,
and
鹵15V
APPLICATIONS
s
s
s
s
s
Wideband Amplifiers
Buffers
Active Filters
Data Acquisition Systems
Photodiode Amplifiers
TYPICAL APPLICATION
A
V
= 鈥? Large-Signal Response
100kHz, 4th Order Butterworth Filter
6.81k
100pF
5.23k
47pF
6.81k
V
IN
11.3k
330pF
鈥?/div>
LT1354
5.23k
10.2k
1000pF
鈥?/div>
LT1354
V
OUT
+
+
1354 TA01
U
U
U
1354 TA02
1
