Optoway
LT-94B73B-PWG / LT-94B73B-PW-AG
LT-94B73B-PWG
1
*****************************************************************************************************************************************************************************
(RoHS Compliant)
3.3V / 2.488 Gbps 1490 nm Continuous-Mode TX /
1.244 Gbps 1310 nm Burst-Mode RX with Burst-Mode Signal Detect,
ITU-T G.984.2 G-PON
CLASS B+
2X6 SFF OLT Transceiver
(with Reset-Less RX)
****************************************************************************************************************************************************************************
l
Class B+ Optical Line Terminal (OLT) for ITU-T G.984.2
Gigabit-capable PON
l
2.488 Gbps / 1490 nm Continuous-Mode Transmitter
l
1.244 Gbps / 1310 nm Burst-Mode Receiver with 2R
Output
l
Resetless
BM Receiver Design
l
BM RX with 32 Bits Packet-to-packet Guard Time for
over 15dB Packet Optical Power Difference
l
0 to 70
o
C Operating: LT-94B73B-PWG
l
-20 to 85
o
C Operating: LT-94B73B-PW-AG
l
2x6 SFF Package with SC/PC Pigtail
l
Single +3.3 V Power Supply
l
RoHS Compliant
l
Transmitter: AC Coupling Input
l
Receiver: DC Coupling Output
l
LVTTL TX Shutdown Input
l
LVTTL TX Laser Failure Alarm Output
l
LVTTL High-Speed Burst-mode RX Signal Detect
l
Analog RX Received Power Monitor
l
Wave Solderable and Aqueous Washable
l
Class 1 Laser International Safety Standard IEC-60825
Compliant
FEATURES
APPLICATIONS
DESCRIPTION
l
Broadband G-PON System
LT-94B73B series is ITU-T G.984.2 Class B+ optical line
terminal (OLT) for 2.488 Gbps/1490 nm in downstream and
1.244 Gbps/1310 nm in upstream. The transmitter section uses
a multiple quantum well 1490 nm DFB laser and is a class 1
laser compliant according to International Safety Standard
IEC-60825. The receiver section uses an integrated 1310 nm
burst-mode detector preamplifier (IDP) mounted in an optical
header and a burst-mode limiting post-amplifier IC.
Unlike
the conventional BM RX, the RX does not requires reset
pulse to receive optical data packets with different optical
power.
LVPECL interface is used for differential inputs and
outputs. A LVTTL logic interface simplifies interface to
external circuitry.
LASER SAFETY
This single mode transceiver is a Class 1 laser product. It
complies with IEC-60825 and FDA 21 CFR 1040.10 and
1040.11. The transceiver must be operated within the
specified temperature and voltage limits. The optical ports of
the module shall be terminated with an optical connector or
with a dust plug.
RX
Temp
(
o
C)
SFF 2X6
SFF 2X6
SFF 2X6
(dBm)
1310
1310
1310
-8 / -28 0 / 70
-8 / -28
-20 / 85
-8 / -29 0 / 70
Yes
Yes
Yes
Package
RoHS
Compliant
ORDER INFORMATION
P/No
Class
Type
LT-94B73B-PWG
LT-94C73C-PWG
B+
C
CNT
CNT
CNT
Speed
(Gb/s)
2.488
2.488
2.488
1490 DFB
1490 DFB
1490 DFB
LT-94B73B-PW-AG
B+
TX
位
(nm)
Power Type
(dBm)
Speed
位
(nm) Sens.
(Gb/s)
1.5 / 5 BM, 2R 1.244
1.5 / 5 BM, 2R 1.244
7 / 3 BM, 2R 1.244
NOTE: 1. LT-XXXXXX-PWXG, SC/PC pigtail with fiber length 50 cm.
2. BM: Burst Mode; CNT: Continuous Mode; SFF: Small Form Factor Package.
*****************************************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax: 886-3-5979737
E-mail: sales@optoway.com.tw http: // www.optoway.com.tw
5/1/2006 V1.0
