Hyper TOPLED

廬

Hyper-Bright Low Current LED

LS T67K, LO T67K, LY T67K

Besondere Merkmale

鈥?/div>

Geh盲usetyp:

wei脽es P-LCC-2 Geh盲use,

farbloser klarer Verguss

鈥?/div>

Besonderheit des Bauteils:

extrem breite

Abstrahlcharakteristik; ideal f眉r

Hinterleuchtungen und Einkopplungen in

Lichtleiter

鈥?/div>

Wellenl盲nge:

630 nm (super-rot),

606 nm (orange), 587 nm (gelb)

鈥?/div>

Abstrahlwinkel:

Lambertscher Strahler (120擄)

鈥?/div>

Technologie:

InGaAlP

鈥?/div>

optischer Wirkungsgrad:

6 lm/W (gelb)

5 lm/W (super-rot), 9 lm/W (orange)

鈥?/div>

Gruppierungsparameter:

Lichtst盲rke,

Wellenl盲nge

鈥?/div>

Verarbeitungsmethode:

f眉r alle

SMT-Best眉cktechniken geeignet

鈥?/div>

L枚tmethode:

IR Reflow L枚ten und

Wellenl枚ten (TTW)

鈥?/div>

Vorbehandlung:

nach JEDEC Level 2

鈥?/div>

Gurtung:

8-mm Gurt mit 2000/Rolle, 酶180 mm

oder 8000/Rolle, 酶330 mm

鈥?/div>

ESD-Festigkeit:

ESD-sicher bis 2 kV nach

JESD22-A114-B

Anwendungen

鈥?Informationsanzeigen im Innenbereich

(z. B. im Laufschriftanzeigen)

鈥?optischer Indikator

鈥?Einkopplung in Lichtleiter

鈥?Hinterleuchtung (LCD, Handy, Schalter, Tasten,

Displays, Werbebeleuchtung)

鈥?Innenbeleuchtung im Automobilbereich

(z.B. Instrumentenbeleuchtung)

鈥?Markierungsbeleuchtung

鈥?Signal- und Symbolleuchten

2003-09-18

Features

鈥?/div>

package:

white P-LCC-2 package, colorless

clear resin

鈥?/div>

feature of the device:

extremely wide viewing

angle; ideal for backlighting and coupling in light

guides

鈥?/div>

wavelength:

630 nm (super-red),

606 nm (orange), 587 nm (yellow)

鈥?/div>

viewing angle:

Lambertian Emitter (120擄)

鈥?/div>

technology:

InGaAlP

鈥?/div>

optical efficiency:

6 lm/W (yellow)

5 lm/W (super-red), 9 lm/W (orange)

鈥?/div>

grouping parameter:

luminous intensity,

wavelength

鈥?/div>

assembly methods:

suitable for all

SMT assembly methods

鈥?/div>

soldering methods:

IR reflow soldering and

TTW soldering

鈥?/div>

preconditioning:

acc. to JEDEC Level 2

鈥?/div>

taping:

8 mm tape with 2000/reel, 酶180 mm or

8000/reel, 酶330 mm

鈥?/div>

ESD-withstand voltage:

up to 2 kV acc. to

JESD22-A114-B

Applications

鈥?indoor displays (e.g. light writing displays)

鈥?optical indicators

鈥?coupling into light guides

鈥?backlighting (LCD, cellular phones, switches,

keys, displays, illuminated advertising)

鈥?interior automotive lighting

(e.g. dashboard backlighting)

鈥?marker lights

鈥?signal and symbol luminaire
