LSI5464E
Ethernet Host Adapter
KEY APPLICATIONS
鈥?NAS
鈥?SAN
鈥?Enterprise servers
鈥?Firewalls
鈥?Email, file and print servers
The LSI5464E offers 4 Ethernet ports, conserving valuable PCI slots.
FEATURES
鈥?100 BASE-TX and 10 base-T
auto-sensing
鈥?4 10/100 external Ethernet
connectors
鈥?800 MBps transfer rates
鈥?Sun SPARC driverless
installation
鈥?Sun SPARC OpenBoot support
鈥?Five year limited warranty
BOOST PERFORMANCE AND CONNECTIVITY IN YOUR
ENTERPRISE NETWORKS
The LSI5464E Quad Port Ethernet adapter is ideal for use in high
connectivity, multiple network environments. It has the performance and
reliability needed by today鈥檚 clustered and data intensive applications. The
LSI5464E contains 4 independent 10/100 Ethernet connections on one PCI
board, allowing the highest levels of system performance and conserving
valuable PCI slots.
The LSI5464E-I adapter is fully interoperable with existing Ethernet
equipment and operates at 800 MBps in full-duplex mode.
WARRANTY
Host Bus:
64-bit, 66 MHz PCI
(backward compatible with
32-bit, 33 MHz buses)
Ethernet Standards:
IEEE 802.3 10 Base-T
IEEE 802.3u 100 Base-TX
auto-sense
Performance:
800 MBps in full duplex
Connector Configuration:
External: (4) RJ-45 UTP
For more than 15 years, LSI Logic host adapters have been providing high-
performance SCSI solutions to leading server, disk array and computer systems
worldwide. Each host adapter carries a powerful chip built in LSI Logic鈥檚
ISO 9001-certified fabrication facilities. Using only the highest quality
components, LSI Logic host adapters are assembled and tested in world-class
facilities to assure superior product reliability and performance. Because of
stringent quality management programs, our host adapters carry a five-year
limited warranty.
LSI5464E GIGABIT ETHERNET ORDERING INFORMATION
LSI5464E-I
LSI5464E-S
X86 (Intel) and Alpha platforms
Sun SPARC platforms
1
2
