products. These Dual Channel, 2 Gbit PCI-to-Fibre Channel host
adapters are designed in a Low Profile PCI form factor making them
the right choice for 1U and 2U rackmount and standard servers, while
providing the performance needed for enterprise applications. These adapters
save valuable PCI slots and offer increased connectivity by providing two
independent fibre channels on one host adapter for clustered or SAN
environments.
The LSI44929 MiniHAB adapters host the LSIFC929, PCI-to-Dual
Channel Fibre Channel controller. The LSIFC929 connects directly to a
64-bit/66 MHz PCI bus presenting one electrical load. The host PCI
interface is PCI 2.2 compliant and is backwards compatible with 32-bit
and 33 MHz buses.
FEATURES
鈥?Two independent, 2 Gbit
channels (up to 400 MBps,
full duplex)
鈥?Low profile PCI form factor
鈥?Auto-negotiation for legacy
connect (1or 2 Gbit)
鈥?64-bit, 66 MHz host PCI bus
(backwards compatible with
32-bit and 33 MHz buses)
鈥?Multi-mode optics and
copper options
鈥?Concurrent SCSI and IP protocol
鈥?Supports target mode and
SCSI initiator, concurrently
鈥?FC-Tape support
鈥?CIM based server management
鈥?Supports all major
operating systems
鈥?Fusion-MPT
鈩?/div>
architected
鈥?SANmark
鈩?/div>
approved
鈥?5 year limited warranty
鈥?SNIA HBA API compliant
LSI44929 ORDERING INFORMATION
LSI44929O
LSI44929LO
LSI44929H
LSI44929LH
Standard height bracket, LC, SFF, multi-mode optics
Low profile bracket, LC, SFF, multi-mode optics
Standard height bracket, HSSDC, copper
Low profile bracket, HSSDC, copper
NOTE: Switch, loop, and point-to-point topologies are supported.
