bracket, LC, SFF, multi-mode optics.
鈩?/div>
family of products is an ideal
solution. These single channel, 2 Gbit PCI-to-Fibre Channel adapters are
multi-purpose fibre channel adapters suitable for many applications needing
low cost fibre channel connectivity. Designed in a Low Profile PCI form factor,
these adapters are perfect for both rackmount and standard servers. The
LSI40919 adapters feature 2 Gbit performance for connecting to high
performance disk drives, RAID subsystems and JBOD mass storage systems.
The LSI40919 adapters host the LSIFC919 multi-function controller for its
PCI and fibre channel functionality creating a higher performance solution.
The host PCI interface is PCI 2.2 compliant and backwards compatible with
32-bit and 33 MHz buses.
FEATURES
鈥?Low profile PCI form factor
鈥?Auto-negotiation for legacy
connect (1 or 2 Gbit)
鈥?64-bit, 66 MHz host PCI bus
(backwards compatible with
32-bit and 33 MHz buses)
鈥?Multi-mode optics and
copper options
鈥?Concurrent SCSI and IP protocol
鈥?Supports target mode and
SCSI initiator, concurrently
鈥?FC-Tape support
鈥?CIM based server management
鈥?Supports all major
operating systems
鈥?Fusion-MPT鈩?architected
鈥?SANmark鈩?approved
鈥?5 year limited warranty
鈥?SNIA HBA API compliant
FUSION-MPT ARCHITECTURE
Based on industry standard ARM technology, the LSI Logic 2 Gbit product
family incorporates Fusion-MPT architecture, a single binary device driver for
Fibre Channel, SCSI and emerging interface technologies such as InfiniBand,
Serial ATA and others. Thinner drivers allow for better and more versatile
performance while adding value at the firmware level. Fusion-MPT provides
the flexibility and rich feature set to make options like Integrated Mirroring
possible for boot volume protection at no additional cost.
廬
LSI40919 ORDERING INFORMATION
LSI40919O
LSI40919LO
LSI40919H
LSI40919LH
Standard height bracket, LC, SFF, multi-mode optics
Low profile bracket, LC, SFF, multi-mode optics
Standard height bracket, HSSDC, copper
Low profile bracket, HSSDC, copper
NOTE: Switch, loop, and point-to-point topologies are supported.
