鈥?Connectors for off-board SCSI
active LEDs
鈥?Any drive in a disk array can
be used as the boot device
鈥?On-board BIOS supports
disk drives with greater than
8-Gbyte capacity
The LSI22801 is a PCI-dual channel
multi-function, single-ended Ultra
SCSI solution.
OVERVIEW
The LSI22801 host adapter is a multi-function board providing two
independent single-ended Ultra SCSI channels. Both SCSI channels are
identical, offering increased connectivity without utilizing additional PCI
slots. A single board provides a powerful dual channel, multitasking interface
for Ultra SCSI peripherals such as disk, tape, CD-ROM, and other SCSI devices.
The LSI22801 leverages the LSI53C876 PCI dual channel SCSI multi-
function controller capable of connecting directly to the PCI bus, presenting
one electrical load, while functioning as a single 32-bit PCI DMA bus master.
The LSI22801 includes an on-board configuration utility allowing
viewing and changing of default configuration settings for the host adapter
and connected SCSI peripherals.
The device also provides advanced features for ease of use by modifying
the on-board terminators depending on cable configuration and LEDs to
help with termination power (TERMPWR) monitoring.
The LSI22801 has advanced features which makes it the right choice for
applications requiring up to 30 connected peripherals, or for isolating
peripheral classes (e.g. CD-ROMs and tape drives on one channel and high
performance disk drives on the other).
