removable drives, scanners, etc.
鈩?/div>
domain validation
technology ensures data integrity
鈥?Supports all major operating
systems with SDMS software
鈥?Supports one-button disaster
recovery for tape drives for
rapid data recovery
鈥?5 year limited warranty
PCI Bus:
32-bit, 33 MHz PCI
SCSI Bus:
16-bit LVD or Single-ended
SCSI Performance:
Ultra160 (160 MBps)
SCSI Connector Config:
Internal: (2) 68-pin HD,
50-pin ribbon
External: 50-pin HD
Max No of SCSI Devices:
30
The LSI21003 Ultra160 SCSI host adapter offers high performance internal
Ultra160 SCSI performance with internal/external legacy SCSI support.
BRING HIGH PERFORMANCE AND FLEXIBILITY TO YOUR
ENTRY LEVEL APPLICATIONS
The LSI Logic LSI21003 Dual Channel Ultra160 SCSI host adapter
is ideal for entry level workstations and high-end desktop applications.
The adapter features Ultra160 SCSI performance when connecting high
performance disk drives internally, and legacy SCSI for internal and external
connection to existing SCSI drives and peripherals.
This adapter provides the advanced features necessary to ensure reliable
Ultra160 system operation and is in position to meet the data transfer
requirements of emerging system technologies. It includes LSI Logic SureLINK
domain validation technology, an innovation available exclusively from
LSI Logic, that ensures data integrity by intelligently testing the network
before completing negotiation.
WARRANTY
For more than 15 years, LSI Logic host adapters have been providing high-
performance SCSI solutions to leading server, disk array and computer systems
worldwide. Each host adapter carries a powerful chip built in LSI Logic鈥檚
ISO 9001-certified fabrication facilities. Using only the highest quality
components, LSI Logic host adapters are assembled and tested in world-class
facilities to assure superior product reliability and performance. Because of
stringent quality management programs, our host adapters carry a five-year
limited warranty.
LSI21003 ORDERING INFORMATION
LSI21003
Supports Intel platforms
