The LSI20160 Ultra160 SCSI host adapter is our lowest cost adapter for any
application needing to add a SCSI adapter.
G E T A L O W C O S T, H I G H P E R F O R M A N C E S O L U T I O N F O R
ANY APPLICATION
The LSI Logic LSI20160 Single Channel Ultra160 SCSI host adapter is
our 鈥渁ll purpose鈥?SCSI adapter. This adapter is ideal for any application
needing added SCSI connectivity at a low cost. The LSI20160 adapter features
Ultra160 SCSI performance both internally when connecting high perform-
ance disk drives and externally when connecting to drives and peripherals.
This adapter provides the advanced features necessary to ensure reliable
Ultra160 system operation and meets the data transfer requirements of
emerging system technologies. It includes LSI Logic SureLINK domain validation
technology, available exclusively from LSI Logic, that ensures data integrity
by intelligently testing the network before completing negotiation.
鈥?Supports all major operating
systems with SDMS software
鈥?Supports one-button disaster
recovery for tape drives for
rapid data recovery
鈥?5 year limited warranty
PCI Bus:
32-bit, 33 MHz PCI
SCSI Bus:
16-bit LVD or Single-ended
SCSI Performance:
Ultra160 (160 MBps)
SCSI Connector Config:
Internal: 68-pin HD
External: 68-pin VHDCI
Max No of SCSI Devices:
15
WARRANTY
For more than 15 years, LSI Logic host adapters have been providing high-
performance SCSI solutions to leading server, disk array and computer systems
worldwide. Each host adapter carries a powerful chip built in LSI Logic鈥檚
ISO 9001-certified fabrication facilities. Using only the highest quality
components, LSI Logic host adapters are assembled and tested in world-class
facilities to assure superior product reliability and performance. Because of
stringent quality management programs, our host adapters carry a five-year
limited warranty.
LSI20160 ORDERING INFORMATION
LSI20160
LSI20160L
Full high ISA/EISA bracket
Low profile bracket
1
2
