Part Number:
LSG12W
www.SunLED.com
T-1 3/4 (5mm) SOLID STATE LAMP
Features
LOW POWER CONSUMPTION.
POPULAR T-1 3/4 DIAMETER PACKAGE.
GENERAL PURPOSE LEADS.
RELIABLE AND RUGGED.
LONG LIFE - SOLID STATE RELIABILITY.
AVAILABLE ON TAPE AND REEL.
RoHS COMPLIANT.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is 鹵 0.25(0.01") unless otherwise noted.
3.Specifications are subject to change without notice.
Absolute Maximum Ratings
(T
A
=25擄C)
Reverse Voltage
Forward Current
Forward Current (Peak)
1/10 Duty Cycle
0.1ms Pulse Width
Power Dissipation
Operating Temperature
Storage Temperature
Lead Solder Temperature
[2mm Below Package Base]
Lead Solder Temperature
[5mm Below Package Base]
V
R
I
F
i
FS
P
T
T
A
Tstg
Operating Characteristics
(T
A
=25擄C)
Forward Voltage (Typ.)
(I
F
=20mA)
Forward Voltage (Max.)
(I
F
=20mA)
Reverse Current (Max.)
(V
R
=5V)
Wavelength of Peak
Emission (Typ.)
(I
F
=20mA)
Wavelength of Dominant
Emission (Typ.)
(I
F
=20mA)
Spectral Line Full Width
At Half-Maximum (Typ.)
(I
F
=20mA)
Capacitance (Typ.)
(V
F
=0V, f=1MHz)
V
F
V
F
I
R
SG
(InGaAlP)
5
30
150
75
-40 ~ +85
-40 ~ +85
Unit
V
mA
mA
mW
擄C
SG
(InGaAlP)
2.1
2.5
10
Unit
V
V
uA
位
P
574
nm
位
D
568
nm
260擄C For 3 Seconds
260擄C For 5 Seconds
螖位
26
nm
C
20
pF
Part
Number
Emitting
Color
Emitting
Material
Lens-color
Luminous
Intensity
(IF=20mA)
mcd
min.
typ.
995
Wavelength
nm
位
P
Viewing
Angle
2
胃
1/2
LSG12W
Green
InGaAlP
Water Clear
480
574
20擄
Published Date : MAR 26, 2008
Drawing No : SDSA0695
V6
Checked : B.L.LIU
P.1/4
