Universal input
2鈥?x 4鈥?footprint
Remote sense
Overload and short circuit protection
Adjustable Output Voltage
High efficiency
High MTBF
Built in EMI filter (CISPR 22 Class B)
LED power good indicator
Input power <74 watts
Complies with EN61000-3-2
UL Class I approved
UL Class II available, consult factory
Output
Maximum power
Adjustment range
Hold-up time
Overload protection
60 W for convection (LPS52, 55W)
鹵20% minimum
10/20 ms 115/230 VAC Input line
Short circuit protection on all outputs.
Case overload protected @ 110-160% of
normal rating
30-50% above nominal output
Compensates for 0.5 V lead drop max.
Will operate without remote sense
connected. Reverse connection
protected.
Overvoltage protection
Remote sense
Environmental
Operating temperature: 0擄 to 50擄C ambient derate
each output as 2.5% per degree from 50擄 to 70擄C.
-20擄C start up.
Storage temperature: -40擄C to +85擄C
Electromagnetic susceptibility:
designed to meetEN61000-4;
-2, -3, -4, -5, -6, -8, -11 Level 3
Humidity: Operating; non-condensing 10% to
95%RH
Vibration: IEC68-2-6 to the levels of IEC721-3-2
MTBF demonstrated: >550,000 hours at full load
and 25擄C ambient conditions.
Safety
UL
CSA
NEMKO
TUV
CB
CE
CCC
UL 60950-1
CSA-C22.2 No. 60950-1
IEC/EN60950-1
EN60950-1
Certificate and report
LVD & EMC
GB4943
74
Americas: 1-888-41-ASTEC
Europe (UK): 44 (1384) 842-211
Asia (HK): 852-2437-9662
rev 08.16.05
