LPC47N350 Datasheet

  • LPC47N350

  • LEGACY FREE KEYBOARD EMBEDDED CONTROLLER WITH SPI AND LPC DO...

  • 346頁

  • SMSC   SMSC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

LPC47N350
Legacy-Free
Keyboard/Embedded
Controller with SPI and
LPC Docking Interface
Datasheet
鈥?Multiple Clock Sources and Operating
Frequencies
鈥?IDLE and SLEEP Modes
鈥?Fail-Safe Ring Oscillator
Real-Time Clock
鈥?MC146818 and DS1287 Compatible
鈥?256 Bytes of Battery Backed CMOS in Two 128-
Byte Banks
鈥?128 Bytes of CMOS RAM Lockable in 4x32-Byte
Blocks
鈥?12- and 24-Hour Time Format
鈥?Binary and BCD Format
鈥?<2碌A(chǔ) Standby Current (typ)
Two 8584-Style I
2
C/SMBus Controllers
鈥?8051 Controlled Logic Allows I
2
C/SMBus Master
or Slave Operation
鈥?I
2
C/SMBus Controllers are Fully Operational on
Standby Power
鈥?2 Sets of Dedicated Pins per I
2
C/SMBus
Controller
Serial Peripheral Interface (SPI)
Four independent Hardware Driven PS/2 Ports
41 General Purpose I/O Pins
鈥?25 Maskable Hardware Wake-Event Capable
鈥?6 Programmable Open-Drain/Push-Pull Outputs
Four Programmable Pulse-Width Modulator Outputs
鈥?Independent Clock Rates
鈥?6-Bit Duty Cycle Granularity
鈥?Operational in both Full on and Standby modes
Dual Fan Tachometer Inputs
Debug Port (UART)
鈥?High-Speed 16550A-Compatible UART with 16-
Byte Send/Receive FIFOs
鈥?Programmable Baud Rate Generator
鈥?Relocatable to 480 Different Base I/O Addresses
鈥?15 IRQ Options
XNOR-Chain Test Mode
128-Pin QFP and VTQFP Package
Product Features
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
3.3V Operation with 5V Tolerant Buffers
ACPI 2.0 PC2001 Compliant
LPC Interface with Clock Run Support
鈥?Decode I/O, Memory, and FWH cycles
鈥?Serial IRQ Interface Compatible with Serialized
IRQ Support for PCI Systems
鈥?15 Direct IRQs
鈥?ACPI SCI Interface
鈥?nSMI output and supporting PM registers
鈥?Shadowed write only registers
LPC Switching
鈥?Hot Plug LPC Docking Interface
鈥?Secondary Switchable LPC interface (3.3V only)
Internal 64K Flash ROM
鈥?Programmed From Direct Parallel Interface,
8051, or LPC Host
鈥?2k-Byte Lockable Boot Block
鈥?Can be Programed Without 8051 Intervention
Three Power Planes
鈥?Low Standby Current in Sleep Mode
ACPI Embedded Controller Interface
Configuration Register Set Compatible with ISA Plug-
and-Play Standard (Version 1.0a)
High-Performance Embedded 8051 Keyboard and
System Controller
鈥?Provides System Power Management
鈥?System Watch Dog Timer (WDT)
鈥?8042 Style Host Interface
鈥?Supports Interrupt and Polling Access
鈥?512 Bytes Executable RAM
鈥?512 Bytes Data RAM
鈥?On-Chip Memory-Mapped Control Registers
鈥?Access to RTC and CMOS Registers
鈥?Up to 16x8 Keyboard Scan Matrix
鈥?Two-16 Bit Timer/Counters
鈥?Integrated Full-Duplex Serial Port Interface
鈥?Eleven 8051 Interrupt Sources
鈥?Thirty-Two 8-Bit, Host/8051 Mailbox Registers
鈥?Thirty-Two Maskable Hardware Wake-Up Events
鈥?Fast GATEA20
鈥?Fast CPU_RESET
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
SMSC LPC47N350
DATASHEET
Revision 1.1 (01-14-03)
