Supports up to 4 external components
Supports I/O cycles (No Memory Support)
8-Bit Data Transfer
6-Bit Address Qualification
Write Protection for each component
Data Brief
Serial Ports
鈥?Two Full Function Serial Ports
鈥?High Speed NS16C550 Compatible UARTs with
Send/Receive 16-Byte FIFOs
鈥?Supports 230k and 460k Baud
鈥?Programmable Baud Rate Generator
鈥?Modem Control Circuitry
Infrared Communications Controller
鈥?IrDA v1.2 (4Mbps), HPSIR, ASKIR, Consumer IR
Support
鈥?2 IR Ports
鈥?96 Base I/O Address, 15 IRQ Options and 3 DMA
Options
XNOR Chain
PC99 and ACPI 1.0b Compliant
100-pin STQFP Package
Intelligent Auto Power Management
2.88MB Super I/O Floppy Disk Controller
鈥?Licensed CMOS 765B Floppy Disk Controller
鈥?Software and Register Compatible with SMSC's
Proprietary 82077AA Compatible Core
鈥?Supports One Floppy Drive Directly
鈥?Configurable Open Drain/Push-Pull Output Drivers
鈥?Supports Vertical Recording Format
鈥?16-Byte Data FIFO
鈥?100% IBM Compatibility
鈥?Detects All Overrun and Underrun Conditions
鈥?Sophisticated Power Control Circuitry (PCC) Including
Multiple Powerdown Modes for Reduced Power
Consumption
鈥?DMA Enable Logic
鈥?Data Rate and Drive Control Registers
鈥?Swap Drives A and B
鈥?Non-Burst Mode DMA Option
鈥?48 Base I/O Address, 15 IRQ and 3 DMA Options
鈥?Forceable Write Protect and Disk Change Controls
Multi-Mode Parallel Port with ChiProtect
鈥?Standard Mode IBM PC/XT, PC/AT, and PS/2
Compatible Bidirectional Parallel Port
鈥?Enhanced Parallel Port (EPP) Compatible - EPP 1.7
and EPP 1.9 (IEEE 1284 Compliant)
鈥?IEEE 1284 Compliant Enhanced Capabilities Port
(ECP)
鈥?ChiProtect Circuitry for Protection Against Damage Due
to Printer Power-On
鈥?192 Base I/O Address, 15 IRQ and 3 DMA Options
LPC Bus Host Interface
Multiplexed Command, Address and Data Bus
8-Bit I/O Transfers
8-Bit DMA Transfers
16-Bit Address Qualification
Serial IRQ Interface Compatible with Serialized IRQ
Support for PCI Systems
鈥?PCI nCLKRUN Support
鈥?Power Management Event (IO_PME#) Interface Pin
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Mechanical Package
鈥?100 pin STQFP (12mm x 12mm body size)
Floppy Disk Available on Parallel Port Pins (ACPI
Compliant)
Enhanced Digital Data Separator
鈥?2 Mbps, 1 Mbps, 500 Kbps, 300 Kbps, 250 Kbps Data
Rates
鈥?Programmable Precompensation Modes
SMSC LPC47N267
PRODUCT PREVIEW
Revision 01-03-05
