LMV851 Single/ LMV852 Dual/ LMV854 Quad 8 MHz Low Power CMOS, EMI Hardened Operational
Amplifiers
October 2007
LMV851/LMV852/LMV854
8 MHz Low Power CMOS, EMI Hardened Operational
Amplifiers
General Description
National鈥檚 LMV851/LMV852/LMV854 are CMOS input, low
power op amp ICs, providing a low input bias current, a wide
temperature range of 鈭?0擄C to +125擄C and exceptional per-
formance, making them robust general purpose parts. Addi-
tionally, the LMV851/LMV852/LMV854 are EMI hardened to
minimize any interference so they are ideal for EMI sensitive
applications. The unity gain stable LMV851/LMV852/LMV854
feature 8 MHz of bandwidth while consuming only 0.4 mA of
current per channel. These parts also maintain stability for
capacitive loads as large as 200 pF. The LMV851/LMV852/
LMV854 provide superior performance and economy in terms
of power and space usage. This family of parts has a maxi-
mum input offset voltage of 1 mV, a rail-to-rail output stage
and an input common-mode voltage range that includes
ground. Over an operating supply range from 2.7V to 5.5V the
LMV851/LMV852/LMV854 provide a CMRR of 92 dB, and a
PSRR of 93 dB. The LMV851/LMV852/LMV854 are offered
in the space saving 5-Pin SC70 package, the 8-Pin MSOP
and the 14-Pin TSSOP package.
Features
Unless otherwise noted, typical values at T
A
= 25擄C,
V
SUPPLY
= 3.3V
2.7V to 5.5V
鈻?/div>
Supply voltage
0.4 mA
鈻?/div>
Supply current (per channel)
1 mV max
鈻?/div>
Input offset voltage
0.1 pA
鈻?/div>
Input bias current
GBW
8 MHz
鈻?/div>
87 dB
鈻?/div>
EMIRR at 1.8 GHz
11 nV/
鈭?/div>
Hz
鈻?/div>
Input noise voltage at 1 kHz
4.5 V/碌s
鈻?/div>
Slew rate
Rail-to-Rail
鈻?/div>
Output voltage swing
30 mA
鈻?/div>
Output current drive
Operating ambient temperature range 鈭?0擄C to 125擄C
鈻?/div>
Applications
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
Photodiode preamp
Piezoelectric sensors
Portable/battery-powered electronic equipment
Filters/buffers
PDAs/phone accessories
Medical diagnosis equipment
Typical Application
Sensor Amplifiers Close to RF Sources
20202101
漏 2007 National Semiconductor Corporation
202021
www.national.com
