LMV844MA Datasheet

  • LMV844MA

  • National Semiconductor [CMOS Input, RRIO, Wide Supply Range...

  • NSC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

LMV841 Single/ LMV842 Dual/ LMV844 Quad CMOS Input, RRIO, Wide Supply Range Operational
Amplifiers
October 2007
LMV841/LMV842/LMV844
CMOS Input, RRIO, Wide Supply Range Operational
Amplifiers
General Description
The LMV841/LMV842/LMV844 are low-voltage and low-pow-
er operational amplifiers that operate with supply voltages
ranging from 2.7V to 12V and have rail-to-rail input and output
capability. Their low offset voltage, low supply current, and
MOS inputs make them ideal for sensor interface and battery-
powered applications.
The single LMV841 is offered in the space-saving 5-Pin SC70
package, the dual LMV842 in the 8-Pin MSOP and 8-Pin
SOIC packages, and the quad LMV844 in the 14-Pin TSSOP
and 14-Pin SOIC packages. These small packages are ideal
solutions for area-constrained PC boards and portable elec-
tronics.
Features
Unless otherwise noted, typical values at T
A
= 25擄C, V
+
= 5V.
鈻?/div>
Space saving 5-Pin SC70 package
鈻?/div>
Supply voltage range 2.7V to 12V
鈻?/div>
Guaranteed at 3.3V, 5V and 鹵5V
1 mA per channel
鈻?/div>
Low supply current
4.5 MHz
鈻?/div>
Unity gain bandwidth
133 dB
鈻?/div>
Open loop gain
500 渭V
max
鈻?/div>
Input offset voltage
Input bias current
0.3 pA
鈻?/div>
112 dB
鈻?/div>
CMRR
20 nV/
鈭?/div>
Hz
鈻?/div>
Input voltage noise
鈭?0擄C to 125擄C
鈻?/div>
Temperature range
鈻?/div>
Rail-to-Rail input
鈻?/div>
Rail-to-Rail output
Applications
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
High impedance sensor interface
Battery powered instrumentation
High gain amplifiers
DAC buffer
Instrumentation amplifiers
Active filters
Typical Applications
20168301
漏 2007 National Semiconductor Corporation
201683
www.national.com
