Part Number
:
LMDKVG02M
www.SunLED.com
10mm ROUND LED LAMP
PRELIMINARY SPEC
Features
UNIFORM LIGHT OUTPUT.
LOW POWER CONSUMPTION.
3 LEADS WITH ONE COMMON CATHODE LEAD.
I.C. COMPATIBLE.
LONG LIFE - SOLID STATE RELIABILITY.
RoHS COMPLIANT.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is 鹵 0.25(0.01") unless otherwise noted.
3. Specifications are subject to change without notice.
Absolute Maximum Ratings
(T
A
=25擄C)
Reverse Voltage
Forward Current
Forward Current (peak)
1/10Duty Cycle
0.1ms Pulse Width
Power Dissipation
Operating Temperature
Storage Temperature
Lead Solder Temperature
[2mm Below Package Base]
Lead Solder Temperature
[5mm Below Package Base]
V
R
I
F
i
FS
P
T
T
A
Tstg
MDK
(InGaA
lP)
5
30
185
75
VG
(InGa
AlP)
5
30
150
75
Unit
V
mA
mA
mW
擄C
Operating Characteristics
(T
A
=25擄C)
Forward Voltage (Typ.)
(IF=20mA)
Forward Voltage (Max.)
(IF=20mA)
Reverse Current (Max.)
(V
R
=5V)
Wavelength of Peak
Emission (Typ.)
(I
F
=20mA)
Wavelength of Dominant
Emission (Typ.)
(I
F
=20mA)
Spectral Line Full Width
At Half-Maximum
(Typ.)
(I
F
=20mA)
Capacitance
(V
F
=0V, f=1MHz)
V
F
V
F
I
R
MDK
(InGaA
lP)
1.95
2.5
10
VG
Unit
(InGaAlP)
2.1
2.5
10
V
V
uA
-40 ~ +85
-40 ~ +85
260擄C For 3 Seconds
260擄C For 5 Seconds
位
P
650
574
nm
位
D
635
570
nm
螖位
28
20
nm
C
35
15
pF
Part
Number
Emitting
Color
Emitting
Material
Lens-color
Luminous
Intensity
(IF=20mA)
mcd
min.
typ.
745
89
Wavelength
nm
位
P
Viewing
Angle
2
胃
1/2
LMDKVG02M
Red
Green
InGaAlP
InGaAlP
White Diffused
380
36
650
574
50
擄
Published Date : MAR 20,2008
Drawing No :SDSA4833
V3
Checked : B.L.LIU
P.1/5
