LM4843MH Datasheet

  • LM4843MH

  • Stereo 2W Audio Power Amplifiers with DC Volume Control

  • 19頁

  • NSC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

LM4843 Stereo 2W Audio Power Amplifiers with DC Volume Control
July 2002
LM4843
Stereo 2W Audio Power Amplifiers
with DC Volume Control
General Description
The LM4843 is a monolithic integrated circuit that provides
DC volume control, and stereo bridged audio power amplifi-
ers capable of producing 2W into 4鈩?(Note 1) with less than
1.0% THD or 2.2W into 3鈩?(Note 2) with less than 1.0%
THD.
Boomer
廬
audio integrated circuits were designed specifically
to provide high quality audio while requiring a minimum
amount of external components. The LM4843 incorporates a
DC volume control with stereo bridged audio power amplifi-
ers making it optimally suited for multimedia monitors, por-
table radios, desktop, and portable computer applications.
The LM4843 features an externally controlled, low-power
consumption shutdown mode, and both a power amplifier
and headphone mute for maximum system flexibility and
performance.
Note 1:
When properly mounted to the circuit board, the LM4843MH will
deliver 2W into 4鈩? See the Application Information section for LM4843MH
usage information.
Note 2:
LM4843MH that has been properly mounted to the circuit board and
forced-air cooled will deliver 2.2W into 3鈩?
Key Specifications
n
P
O
at 1% THD+N
n
into 3鈩?/div>
n
into 4鈩?/div>
n
into 8鈩?/div>
n
Shutdown current
2.2W (typ)
2.0W (typ)
1.1W (typ)
0.7碌A(chǔ) (typ)
Features
n
n
n
n
Acoustically Enhanced DC Volume Control Taper
Stereo bridged power amplifiers
鈥淐lick and pop鈥?suppression circuitry
Thermal shutdown protection circuitry
Applications
n
Portable and Desktop Computers
n
Multimedia Monitors
n
Portable Radios, PDAs, and Portable TVs
Block Diagram
20038389
FIGURE 1. LM4843 Block Diagram
Boomer
廬
is a registered trademark of NationalSemiconductor Corporation.
漏 2002 National Semiconductor Corporation
DS200383
www.national.com
