LM358/D Datasheet

  • LM358/D

  • Dual Differential Input， Low Power Operational Amplifiers

  • 12頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

LM358, LM258, LM2904,
LM2904V
Dual Differential Input,
Low Power
Operational Amplifiers
Utilizing the circuit designs perfected for recently introduced Quad
Operational Amplifiers, these dual operational amplifiers feature low
power drain, a common mode input voltage range extending to
ground/V
EE
, single supply or split supply operation and pinouts
compatible with the popular MC1558 dual operational amplifier. The
LM358 series is equivalent to one鈥揾alf of an LM324.
These amplifiers have several distinct advantages over standard
operational amplifier types in single supply applications. They can
operate at supply voltages as low as 3.0 V or as high as 32 V, with
quiescent currents about one鈥揻ifth of those associated with the
MC1741 (on a per amplifier basis). The common mode input range
includes the negative supply, thereby eliminating the necessity for
external biasing components in many applications. The output voltage
range also includes the negative power supply voltage.
鈥?/div>
Short Circuit Protected Outputs
鈥?/div>
True Differential Input Stage
鈥?/div>
Single Supply Operation: 3.0 V to 32 V (LM258/LM358)
3.0 V to 26 V (LM2904, V)
鈥?/div>
Low Input Bias Currents
鈥?/div>
Internally Compensated
鈥?/div>
Common Mode Range Extends to Negative Supply
鈥?/div>
Single and Split Supply Operation
鈥?/div>
Similar Performance to the Popular MC1558
鈥?/div>
ESD Clamps on the Inputs Increase Ruggedness of the Device
without Affecting Operation
http://onsemi.com
PDIP鈥?
N, AN, VN SUFFIX
CASE 626
1
8
8
1
SO鈥?
D, VD SUFFIX
CASE 751
PIN CONNECTIONS
Output A
Inputs A
V
EE
/Gnd
1
2
3
4
8
鈥?/div>
+
7
V
CC
Output B
Inputs B
鈥?/div>
+
5
6
(Top View)
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 9 of this data sheet.
DEVICE MARKING INFORMATION
See general marking information in the device marking
section on page 10 of this data sheet.
漏
Semiconductor Components Industries, LLC, 2001
1
March, 2001 鈥?Rev. 3
Publication Order Number:
LM358/D
