LM323 Datasheet

  • LM323

  • THREE-TERMINAL 3A-5V POSITIVE VOLTAGE REGULATORS

  • 172.52KB

  • 9頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

LM123/LM223
LM323
THREE-TERMINAL 3A-5V POSITIVE VOLTAGE REGULATORS
.
.
.
.
.
OUTPUT CURRENT : 3A
INTERNAL CURRENT AND THERMAL LIMI-
TING
TYPICAL OUPUT IMPEDANCE : 0.01鈩?/div>
MINIMUM INPUT VOLTAGE : 7.5V
POWER DISSIPATION : 30W
TO-3
DESCRIPTION
The LM123, LM223, LM323 are three-terminal posi-
tive voltage regulators with a preset 5V output and
a load driving capability of 3A. New circuit design
and processing techniques are used to provide the
high output current without sacrificing the regulation
characteristics of lower current devices.
The 3A regulator is virtually blowout proof.
Current limiting, power limiting and thermal shut-
down provide the same high level of reliability ob-
tained with these techniques in the LM209, 1A regu-
lator.
An overall worst case specification for the combined
effects of input voltage, load current, ambient tem-
perature, and power dissipation ensure that the
LM123, LM223, LM323 will perform satisfactorily as
a system element.
TO-220
ORDER CODES
Part Number
LM123
LM223
LM323
Temperature
Range
-55 C to 150 C
-25 C to 150 C
0
o
C to 125
o
C
o
o
o
o
Package
K
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
T
PIN CONNECTION
TO-3
(bottom view)
TO-220
(front view)
1 - Input
2 - Output
3 - GND
1 - Input
2 - Output
March 1993
1/9
