LM2429 Monolithic Triple Channel 15 MHz DTV Driver
October 2004
LM2429
Monolithic Triple Channel 15 MHz DTV Driver
General Description
The LM2429 is an integrated high voltage CRT driver circuit
designed for use in DTV applications. The IC contains three
high input impedance, wide band amplifiers which directly
drive the RGB cathodes of a CRT. Each channel has its gain
internally set to 鈭?1 and can drive CRT capacitive loads as
well as resistive loads present in other applications, limited
only by the package鈥檚 power dissipation.
The IC is packaged in an industry standard 11-lead TO-220
molded plastic power package designed specifically to meet
high voltage spacing requirements. See Thermal Consider-
ations section.
Features
n
0V to 5V input range
n
Greater than 130V
PP
output swing capability
n
Stable with 0鈥?0 pF capacitive loads and inductive
peaking networks
n
Convenient TO-220 staggered thin lead package style
Applications
n
AC coupled DTV applications using the 480p format as
well as standard NTSC and PAL formats.
Connection Diagram
Schematic Diagram
20073102
Note:
Tab is at GND
Top View
Order Number LM2429
20073101
FIGURE 1. Simplified Connection and Pinout Diagram
FIGURE 2. Simplified Schematic Diagram
(One Channel)
漏 2004 National Semiconductor Corporation
DS200731
www.national.com
