LM2402 Monolithic Triple 3 ns CRT Driver
August 1999
LM2402
Monolithic Triple 3 ns CRT Driver
General Description
The LM2402 is an integrated high voltage CRT driver circuit
designed for use in high resolution color monitor applica-
tions. The IC contains three high input impedance, wide
band amplifiers which directly drive the RGB cathodes of a
CRT. Each channel has its gain internally set to 鈭?4 and can
drive CRT capacitive loads as well as resistive loads pre-
sented by other applications, limited only by the package鈥檚
power dissipation.
The IC is packaged in an industry standard 11 lead TO-220
molded plastic power package. See thermal considerations
on page 5.
Well matched with LM2202 video preamps
Output swing capability: 50 V
PP
for V
CC
= 80V
1V to 5V input range
Stable with 0-20 pF capacitive loads and inductive
peaking networks
n
Convenient TO-220 staggered lead package style
n
Standard LM240X family pinout which is designed for
easy PCB layout
n
n
n
n
Applications
n
CRT driver for color monitors with display resolutions up
to 1600 x 1200
n
Pixel clock frequency up to 200 MHz
Features
n
Rise/fall times typically 3.0/2.8 ns with 8 pF load at
40 V
PP
Schematic and Connection Diagrams
DS101016-1
DS101016-2
FIGURE 1. Simplified Schematic Diagram
(One Channel)
Top View
Order Number LM2402T
漏 1999 National Semiconductor Corporation
DS101016
www.national.com
