LM129AH/883 Datasheet

  • LM129AH/883

  • Precision Reference

  • 10頁

  • NSC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

LM129/LM329 Precision Reference
March 2000
LM129/LM329
Precision Reference
General Description
The LM129 and LM329 family are precision multi-current
temperature-compensated 6.9V zener references with dy-
namic impedances a factor of 10 to 100 less than discrete di-
odes. Constructed in a single silicon chip, the LM129 uses
active circuitry to buffer the internal zener allowing the de-
vice to operate over a 0.5 mA to 15 mA range with virtually
no change in performance. The LM129 and LM329 are avail-
able with selected temperature coefficients of 0.001, 0.002,
0.005 and 0.01%/藲C. These references also have excellent
long term stability and low noise.
A new subsurface breakdown zener used in the LM129 gives
lower noise and better long-term stability than conventional
IC zeners. Further the zener and temperature compensating
transistor are made by a planar process so they are immune
to problems that plague ordinary zeners. For example, there
is virtually no voltage shift in zener voltage due to tempera-
ture cycling and the device is insensitive to stress on the
leads.
The LM129 can be used in place of conventional zeners with
improved performance. The low dynamic impedance simpli-
fies biasing and the wide operating current allows the re-
placement of many zener types.
The LM129 is packaged in a 2-lead TO-46 package and is
rated for operation over a 鈭?5藲C to +125藲C temperature
range. The LM329 for operation over 0藲C to 70藲C is available
in both a hermetic TO-46 package and a TO-92 epoxy pack-
age.
Features
n
n
n
n
n
n
n
n
0.6 mA to 15 mA operating current
0.6鈩?dynamic impedance at any current
Available with temperature coefficients of 0.001%/藲C
7碌V wideband noise
5% initial tolerance
0.002% long term stability
Low cost
Subsurface zener
Connection Diagrams
Metal Can Package (T0鈥?6)
Plastic Package (TO-92)
DS005714-4
DS005714-6
Pin 2 is electrically connected to case
Bottom View
Order Number LM129AH, LM129AH/883, LM129BH,
LM129BH/883, LM129CH, LM329AH, LM329BH,
LM329CH or LM329DH
See NS Package H02A
Bottom View
Order Number LM329BZ,
LM329CZ or LM329DZ
See NS Package Z03A
漏 2000 National Semiconductor Corporation
DS005714
www.national.com
