LH168R Datasheet

  • LH168R

  • 384-output TFT-LCD Source Driver IC

  • 19頁

  • SHARP

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

LH168R
LH168R
DESCRIPTION
The LH168R is a 384-output TFT-LCD source
driver IC which can simultaneously display 16.7
million colors in 256 gray scales.
384-output TFT-LCD Source Driver IC
PIN CONNECTIONS
464-PIN TCP
XO
1
1
YO
1
2
ZO
1
3
TOP VIEW
FEATURES
鈥?Number of LCD drive outputs : 384
鈥?Built-in 8-bit digital input DAC
鈥?Dot-inversion drive : Outputs the inverted gray
scale voltages between LCD drive pins next to
each other
鈥?2-port input for each circuit of data inputs R, G
and B, and it is possible to sample and hold
display data of two pixels at the same time
鈥?Possible to display 16.7 million colors in 256 gray
scales with reference voltage input of 18 gray
scales : This reference voltage input corresponds
to 鈥?correction and intermediate reference voltage
input can be abbreviated
鈥?Cascade connection
鈥?Sampling sequence :
Output shift direction can be selected
XO
1
, YO
1
, ZO
1
/XO
128
, YO
128
, ZO
128
or
ZO
128
, YO
128
, XO
128
/ZO
1
, YO
1
, XO
1
鈥?Shift clock frequency : 65 MHz (MAX.)
鈥?Supply voltages
鈥?V
CC
(for logic system) : +2.5 to +3.6 V
鈥?V
LS
(for LCD drive) : +13 V (MAX.)
鈥?Package : 464-pin TCP (Tape Carrier Package)
464
463
462
461
GND
V
LS
GND
XB
7
454 XB
0
453 XA
7
446 XA
0
445 YA
7
438
437
436
435
434
433
432
431
430
429
428
427
426
425
424
423
422
421
420
419
418
417
416
415
414
413
412
YA
0
SPOI
VH
0
VH
32
VH
64
VH
96
VH
128
VH
160
VH
192
VH
224
VH
256
VL
256
VL
224
VL
192
VL
160
VL
128
VL
96
VL
64
VL
32
VL
0
POLB
POLA
CK
SPIO
LS
REV
YB
7
CHIP SURFACE
405 YB
0
404 ZB
7
397 ZB
0
396 ZA
7
389
388
387
386
385
ZA
0
LBR
V
CC
V
LS
GND
XO
128
382
YO
128
383
ZO
128
384
NOTE :
Doesn't prescribe TCP outline.
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP devices shown in
catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
