LH1518AT Datasheet

  • LH1518AT

  • 1 Form A Solid State Relay

  • 8頁

  • VISHAY   VISHAY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

VISHAY
LH1518AAB/ AABTR/ AT
Vishay Semiconductors
1 Form A Solid State Relay
DIP
SMD
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Isolation Test Voltage 5300 V
RMS
Current-limit Protection
Linear AC/DC Operation
High-reliability Monolithic Detector
Low Power Consumption
Clean, Bounce-free Switching
High Surge Capability
Surface Mountable
S
6
DC
5
S'
4
S
S'
i179001
1
2
3
Agency Approvals
UL - File No. E52744 System Code H or J
CSA - Certification 093751
BSI/BABT Cert. No. 7980
DIN EN 60747-5-5 (VDE 0884):2003-01 Available
with Option 1
鈥?FIMKO Approval
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Applications
General Telecom Switching
Instrumentation
Industrial Controls
The relays can switch currents in the range of nano-
amps to hundreds of milliamps. The MOSFET
switches are ideal for small signal switching and are
primarily suited for dc or audio frequency applica-
tions.
The LH1518 relays feature a monolithic output die
that minimizes wire bonds and permits easy integra-
tion of high-performance circuits such as current lim-
iting in normally-open switches. The output die
integrates the photodiode receptor array, turn-on and
turn-off control circuitry, and the MOSFET switches.
The optically-coupled input is controlled by a highly
efficient GaAlAs infrared LED.
Description
Vishay Solid State Relays (SSRs) are miniature, opti-
cally- coupled relays with high-voltage MOSFET out-
puts. The LH1518 relays are capable of switching AC
or DC loads from as little as nanovolts to hundreds of
volts.
Order Information
Part
LH1518AAB
LH1518AABTR
LH1518AT
Remarks
SMD-6, Tubes
SMD-6, Tape and Reel
DIP-6, Tubes
Document Number 83816
Rev. 1.2, 08-Mar-04
www.vishay.com
1

LH1518AT 產品屬性

  • LH1518 Series Solid State Relays

  • 2,000

  • 繼電器

  • 固態

  • LH1518

  • SPST-NO（1 Form A）

  • AC，DC

  • 20 歐姆

  • 300mA

  • 1.26VDC

  • 0 ~ 250 V

  • 通孔

  • PC 引腳

  • 6-DIP（0.300"，7.62mm）

  • 6-DIP

  • 管件

  • 繼電器
