Photointerrupters(Transmissive)
KODENSHI
LG-217
DIMENSIONS
LG-217 photointerrupter combines high output GaAs
IRED with photo IC.
The sensor makes possible easy development of
objectdetecting systems with high performance, high
reliability and small equipment size.
(Unit : mm)
FEATURES
鈥ompatible to TTL and LSTTL
鈥uilt Amplifier and Schumitt Trigger
鈥asy
APPLICATIONS
鈥loppy disk drives
鈥opiers
鈥acsimiles
鈥aper sensors
MAXIMUM RATINGS
Item
Supply voltage
Output voltage
Low level output current
Operating temp.
Storage temp.
(Ta=25鈩?
Symbol
V
CC
max.
Vout
I
OL
Topr.
*1
Tstg.
*1
Rating
8
16
16
-25~+55
-40~+85
Unit
V
V
mA
鈩?/div>
鈩?/div>
*1. The connector shall be inserted or pulled out at normal temperature.
ELECTRO-OPTICAL CHARACTERISTICS
Item
Supply voltage
High level output voltage
Low level output voltage
Output form
Frequency
Current consumption
(Ta=25鈩?
Symbol
V
V
OH
V
OL
CC
Conditions
V
OC
=5V, R
L
=47K惟
V
CC
=5V, I
OL
=15mA
V
CC
=5V, R
L
=47K惟
V
CC
=5V
Min.
45
Typ.
5鹵10%
Max.
0.4
Unit.
V
V
V
-
Hz
mA
NPN
f
I
CC
3,000
35
- 1-
