LC898023KW Datasheet

  • LC898023KW

  • 40ⅴ Playback/16ⅴ Write CD-R/RW Encoder/Decoder IC with Bui...

  • 13頁

  • SANYO

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Ordering number : ENN*6614A
CMOS IC
LC898023KW, 898023KL
40脳 Playback/16脳 Write CD-R/RW Encoder/Decoder IC
with Built-in SCSI Interface
Preliminary
Functions
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
CD-ROM decoder/encoder functions
CD decoder/encoder functions
Pit and wobble CLV servo
CAV audio functions
SCSI interface (includes the register block)
Subcode encoder/decoder functions
ATIP demodulator/ATIP decoder
Supports BURN-Proof recording
Write strategy function (CD-R/RW)
CD-DSP function with built-in digital servo
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
CAV audio functions
Write strategy function supports 16脳 recording.
Built-in SCSI interface (supports Ultra SCSI)
Supports 40脳 decoding and 16脳 encoding.
Clock frequencies: CD-ROM block: 33.8688 MHz,
SCSI block: 20 MHz
Ultra SCSI data transfer rate: 20 Mbyte/s (Maximum
synchronous transfer rate), Fast SCSI: 10 Mbyte/s
(Maximum synchronous transfer rate), 5 Mbyte/s
(Maximum asynchronous transfer rate)
Uses 16-bit data bus 45 ns EDO DRAM.
From 1 to 64 Mbits of buffer RAM can be used. (16-bit
data bus EDO DRAM)
The user can freely set up the CD main channel, C2 flag,
and subcode areas in buffer RAM.
Batch transfer function (Function for transferring the CD
main channel, C2 flag, subcode, and other data in a
single operation)
Multi-transfer function (Function for automatically
transferring multiple blocks to the host in a single
operation)
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Features
鈥?ECC and EDC correction/addition (decoding/encoding)
for CD-ROM data.
鈥?ECC error correction/addition (decoding/encoding) for
subcode data
鈥?Servo control implemented in a digital servo system
(decoding/encoding)
鈥?Wobble CLV servo control using ATIP data (encoding)
鈥?ATIP decoding function and CRC check function
(decoding/encoding)
鈥?CIRC code generation and addition and EFM
modulation (encoding)
鈥?/div>
鈥淏URN-Proof鈥?stands for Proof against Buffer Under RuN
error, not for proof against burning.
鈥淏URN-Proof鈥?is a trademark of SANYO Electric Co.,Ltd.
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft鈥檚
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
20802TN (OT)/82500RM (OT) No. 6614-1/13
