Ordering number : ENN*6749

CMOS IC

LC86E7248

8-Bit Single Chip Microcontroller

with the UVEPROM

Preliminary

Overview

The LC86E7248 is a CMOS 8-bit single chip microcontroller with UVEPROM for the LC867200 series. This

microcontroller has the function and the pin description of the LC867200 series mask ROM version, and 48K-byte EPROM.

The program data is rewritable. It is suitable to develop the program.

Features

(1) Option switching by EPROM data

The option function of the LC867200 series can be specified by the EPROM data.

LC86E7248 can be checked the functions of the trial pieces using the mass production board.

(2) Internal EPROM capacity

: 49408 bytes

(3) Internal RAM capacity

: 1152 bytes

Used EPROM or RAM capacity are equal ROM or RAM capacity of mask ROM version which applies LC86E7248.

Mask ROM version

LC867248

LC867240

LC867232

LC867224

EPROM capacity

49152 bytes

40960 bytes

32768 bytes

24576 bytes

RAM capacity

1152 bytes

1152 bytes

1152 bytes

1152 bytes

(4) Operating supply voltage

: 4.5V to 6.0V

(5) Instruction cycle time

: 1碌s to 366碌s

(6) Operating temperature

: +10擄C to +40擄C

(7) The pin compatible with the LC867200 series mask ROM devices

(8) Applicable mask ROM version

: LC867248/40/32/24

(9) Factory shipment

: QFC100S (with window)

Ver.1.02

80196

91400 RM (IM) SK No.6749-1/19
