Ordering number : EN5681
CMOS LSI
LC75392, 75392M
Single-Chip Electronic Volume Control System
Overview
The LC75392 (DIP-30SD) and the LC75392M (MFP-
30S) are electronic volume control ICs that provide input
and output switching, volume, and tone control functions
controlled by data transferred over a serial interface.
Package Dimensions
unit: mm
3196-DIP30SD
[LC75392]
Functions
鈥?Input and output switching: Four inputs and outputs can
be switched independently.
鈥?Volume control: A balance function can be implemented
by controlling the left and right levels independently.
Each channel can be set to 0 to 鈥?0 dB in 2 dB steps,
鈥?0 to 鈥?2 dB in 3 dB steps, 鈥?2 to 鈥?2 dB in 4 dB
steps, 鈥?2 dB to 鈥?0 dB in 4.5 dB steps, and 鈥撯垶.
鈥one controls: Internal switches are provided to select
between four sets of frequency characteristics. A buffer
function can be implemented using external
components.
SANYO: DIP30SD
unit: mm
3216-MFP30S
[LC75392M]
Features
Serial data interface: Support for control and
communication in the CCB format.
SANYO: MFP30S
Specifications
Absolute Maximum Ratings
at Ta = 25擄C, V
SS
= 0 V
Parameter
Maximum supply voltage
Maximum input voltage
Allowable power dissipation
Operating temperature
Storage temperature
Symbol
V
DD
max
V
IN
max
Pd max
Topr
Tstg
V
DD
CL, DI, CE, L1, L2, L3, L4, R1, R2, R3, R4
Ta
鈮?/div>
85擄C
Conditions
Ratings
12
V
SS
鈥?0.3 to V
DD
+ 0.3
160
鈥?0 to +85
鈥?0 to +125
Unit
V
V
mW
擄C
擄C
鈥?CCB is a trademark of SANYO ELECTRIC CO., LTD.
鈥?CCB is SANYO鈥檚 original bus format and all the bus addresses are controlled by SANYO.
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110 JAPAN
73097HA(OT) No. 5681-1/12
