LC75371M Datasheet

  • LC75371M

  • Car Stereo Electronic Tone and Volume Control

  • 17頁

  • SANYO

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Ordering number : EN5348
CMOS LSI
LC75371M
Car Stereo Electronic Tone
and Volume Control
Overview
The LC75371M is an electronic tone/volume control LSI
that can implement, with minimal external components,
volume, balance, fader, bass and treble, loudness, input
switching, and input level controls.
Package Dimensions
unit: mm
3204-MFP36S
[LC75371M]
Functions
鈥?Volume control: From 0 to 鈥?9 dB in 1-dB steps plus
鈥撯垶 for a total of 81 settings. Since the left and right
levels can be set independently, this function can also be
used to implement a balance function.
鈥?Fader: Attenuates either the rear or front channels to
one of 16 levels. (Provides 16 settings, namely, from 0
to 鈥?0 dB in 2-dB steps, from 鈥?0 to 鈥?5 dB in one
5-dB step, from 鈥?5 to 鈥?5 dB in 10-dB steps, 鈥?0 dB,
and 鈥撯垶.)
鈥?Bass and treble controls: Forms an NF-type tone control
circuit (LUX type) using external capacitors. Provides
15 settings each for the bass and treble controls.
鈥?Loudness control: A loudness function can be
implemented by attaching external RC circuits at the
taps provided from the volume control resistor ladder
starting at the 鈥?0-dB position.
鈥?The input signal can be selected from one of three inputs
for each of the left and right channels. The input signal
can be amplified by between 0 and +18 dB in 6-dB steps.
鈥?Serial data input: Supports CCB* format communication
with the system controller.
SANYO: MFP36S
Features
鈥?Built-in buffer amplifiers allow applications to be
implemented with few external components.
鈥?A V
DD
/2 reference voltage generation circuit is provided
on chip.
鈥?CCB is a trademark of SANYO ELECTRIC CO., LTD.
鈥?CCB is SANYO鈥檚 original bus format and all the bus
addresses are controlled by SANYO.
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110 JAPAN
53096HA (OT) No. 5348-1/17
