Ordering number : ENN*6789
CMOS IC
LC4102C-T2A
LCD Dot Matrix Common Driver for STN Displays
Preliminary
Overview
The LC4102C-T2A is a common driver for large-scale dot
matrix LCD panels. It includes a 160-bit bidirectional shift
register and 4-level LCD driver circuits. The number of
bits can be further increased by using the provided input
and output pins to connect multiple LC4102C-T2A in
cascade. The LC4102C-T2A and the LC4104C-T2A LCD
dot matrix segment driver IC form a large-screen LCD
panel driver chip set.
Features
Fabricated in a CMOS (P-sub) high-voltage process.
LCD drive voltage: 36 V
Logic system power-supply voltage: 2.7 to 5.5 V
fcp max: 2.5 MHz
Bidirectional shift register
The shift register can be split into two 80-bit registers.
(Two screens drivable)
鈥?DISPOFF function that locks the drive voltages output
to the LCD at fixed levels.
鈥?Display duty: 1/160 to 1/480
鈥?Package: TCP (Tape Carrier Package)
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Specifications
The electrical characteristics values shown below are for devices packaged in the SANYO standard PGA-208 package.
Absolute Maximum Ratings
at V
SS
= 0
Parameter
Symbol
V
DD
max
Supply voltage
V
EE
max
V
SSH
max
V
IN
Input voltage
V0, V1
V4
V5
Operating temperature
Storage temperature
Topr
Tstg
V
DD
V
EE
V
SSH
*
1
V0, V1
V4
*
2
V5
*
2
*
2
Applicable pins
Ratings
鈥?.3 to +7.0
鈥?.3 to +40.0
鈥?.3 to +0.3
鈥?.3 to V
DD
+ 0.3
V
EE
鈥?7.0 to V
EE
+ 0.3
鈥?.3 to V
SS
+ 7.0
鈥?.3 to +0.3
鈥?0 to +75
鈥?5 to +125
Unit
V
V
V
V
V
V
V
擄C
擄C
Note: 1. LOAD, RS/LS, DISP, DF, DIO1, DIO160, DMIN and MODE
2. The voltages V0, V1, V4, and V5 must obey the relationships V
EE
鈮?/div>
V0
鈮?/div>
V1
鈮?/div>
V
EE
鈥?7 V, and 7 V
鈮?/div>
V4
鈮?/div>
V5
鈮?/div>
V
SSH
.
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft鈥檚
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
20702TN (OT) No. 6789-1/8
