Ordering number: EN 5578

CMOS LSI

LC11014-241

Computer Image Signal Processing

Full-Color Gray-Scale Processor

Overview

The LC11014-241 is a pseudo gray-scale processor for

TFT-LCD panel displays. It allows TFT-LCD panels with

3, 4, 5 or 6-bit input digital drivers to display the equiva-

lent of 16.7 million colors. It can also be used with XGA

panels in 2-pixel parallel input/output mode.

Package Dimensions

unit: mm

3214-SQFP144

[LC11014-241]

Features

鈥?Handles 8 bits of input data (256-level gray scale data)

for each of the RGB colors

鈥?Realizes reduced resolution loss (as compared to dither-

ing techniques) by using intra-frame and inter-frame

error diffusion processing

鈥?Incorporates a new full-coloration algorithm, formerly

best done using computers

鈥?Operating mode selection of outputs for 3, 4, 5, or 6-bit

drivers

鈥?Selectable 2-pixel parallel input/output, serial-input par-

allel-output, and serial input/output operating modes

鈥?40MHz (parallel input/output), 65 MHz (serial input,

parallel output), or 50MHz (serial input/output) maxi-

mum clock frequency

鈥?Can operate independently of the number of displayed

pixels since internal operation is controlled by the hori-

zontal and vertical synchronization signals.

鈥?Power-save function to stop the internal operation pro-

cessing circuits, and output only the clock, sync signals

and control signals

鈥?Supports 5V input signals at 3.3V supply voltage

SANYO Electric Co., Ltd. Semiconductor Business Headquarters

TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110 JAPAN

61297HA (ID) No. 5578鈥?/13
